Limit Switches
Made in Germany
ASA Schalttechnik – we drive the industry
Are you looking for reasonably priced technology that works smoothly, that
fully meets your requirements and that offers a long service life with constant
high performance as you would expect? And, on top of this, a range of products
that is convincing in terms of both breadth and depth? Then we have the good
news that you have been waiting for: At ASA Schalttechnik we do everything
imaginable so that your wishes become reality.
Our team consists of doers, creative minds and service experts: Experienced
professionals who live and breathe quality, who draw on unlimited resources
on 2.000 m2
production space, are dedicated to detail and who get to the
heart of things when it comes to control and switching technology. Alltogether,
refreshingly pragmatic, truly German, straightforward and good.
We love challenges
Our all-round competence is reflected in our tried and tested standard products that can be delivered at short notice ex-factory. But also in our individual
custom-made solutions manufactured in small volumes. Consequently, we are a
competent partner and, when the need arises, a flexible manufacturer of niche
products, developed and designed in cooperation with our customers.
ASA Schalttechnik proudly stands for this philosophy and delivers every time.
As a family-owned enterprise, our products offer quality “Made in Germany”.
Our product range
Mechanical, magnetic and electronic switchgear for machinery and plant
engineering – control and automation technology, fire protection
technology, medical technology and much more:
• Limit Switches
• Switchgear
• Foot Switches
• Safety Switches
• Medical switching devices
• Magnetic Switches
• Level Switches
• Special switching devices
3
made
in
Germany
Quality is a continuous process
Or to put it another way, it’s a never-ending process – an infinite cycle of testing,
analysing, understanding, learning, optimising and documenting. That‘s life. Our
suppliers also support us with this process, as it’s the only way to make quality
management work. And we make sure to adhere to it: With staying power since 1975.
Enviromental protection is a point of honour
Save electricity, water and heating energy. Avoid waste and plan responsible use
of raw materials in production. For our team, ecology is not just hype – it plays
an important part in our day-to-day operations, also with regard to RoHS, REACH
and recycling. Beneficial to nature, beneficial to us all.
It’s the team that makes the difference
ASA Schalttechnik: People who achieve – hands-on people who think for themselves and who inspire us with their energy, ideas and experience. Whether they
work in our production department, in customer relations or in management, our
committed staff does everything to achieve best prices, top-of-class products,
best delivery times and excellent services. And that’s a promise!
4
ASA limit switches
Ranging from standard switchgear to special designs: ASA limit switches are
used in all areas of machinery and plant engineering – especially control and
automation technology. Extremely successfully where machine processes are queried, controlled, monitored and counted.
Always the right switch
ASA limit switches are functional, precise, reliable and made from high-quality
materials. We have the most suitable type depending on the type of current, the
switching capacity, the actuator travel and the actuating force. Are atmospheric
conditions or temperatures significant in the areas where limit switches are used?
Thanks to our many different switch designs we can provide very specific solutions.
Small and very good
ASA limit switches are small and compact. All switch components are arranged
to save space – relatively high performance can be provided in small spaces.
• Many power stages and different switching systems.
• Gold-plated contacts or positive opening properties according to
IEC/EN 60947-5-1 are available
Please also note the technical details on the following pages.
ASA limit switches
5
Limit switch lines – overview:
SK – SM – SDK – SDM
The SK line includes limiting sub-miniature switches with plastic actuators.
SK Plastic-encapsulated stackable individual limit switches, cable outlets
on the side or bottom, 12 different plastic actuators, 7 different switch
inserts with several power levels and switching systems, standard designs
The SM line includes limiting sub-miniature switches with metal actuators.
SM Plastic-encapsulated stackable individual limit switches, cable
outlets on the side or bottom, 37 different metal actuators, 7 different
switch inserts with several power levels and switching systems,
standard designs
The SDK line includes dual limiting sub-miniature switches with plastic actuators.
SDK Plastic-encapsulated stackable dual limit switches, cable outlets on the
side or bottom, 12 different plastic actuators, 3 different switch inserts
with several power levels and switching systems, standard designs
The SDM line includes dual limiting sub-miniature switches with metal actuators.
SDM Plastic-encapsulated stackable dual limit switches, cable outlets on the side
or bottom, 35 different metal actuators, 3 different switch inserts with several
power levels and switching systems, standard designs
The individual product lines offered by ASA include a wide selection of other
switch designs. Can‘t find a standard solution to match your individual requirements? We look forward to discussing your needs and providing customised special
configurations.
6
Sub-miniature switches SK, SM
TYPE
SK Sub-miniature switch, single
limit switch with plastic actuator
SM Sub-miniature switch, single
limit switch with metal actuator
Current capacity
5 5 Ampere
10 10 Ampere
0.1 0.1 Ampere
4 4 Ampere
8 8 Ampere
Fastening
Z Central fastening attachment
Actuator
S Plunger
T Telescopic plunger
K Small lever, 5 mm wide
G Large lever, 8 mm wide
D Wire
F Spring probe
Positive opening
Z Positive opening according to
IEC/EN 60204 and
IEC/EN 60947-5-1
Cabling
U Cable outlet, bottom
Actuator design
S Plunger
R Roller
90 Roller, 90o
offset
G Slider
K Hinge roller
D Wire
F Spring
Kl Sphere, O 8 mm
Kg Sphere, O 10 mm
Length of actuator
1 to 200 mm
Example: SM 10ZTR U
The limiting sub-miniature switches in the SK and SM lines
The SK line includes plastic-encapsulated, stackable miniature single limit switches with
plastic actuators. This line is a consistent development of the popular SM line. The latter are plasticencapsulated, stackable miniature single limit switches but with metal actuators.
These two lines are used in all areas of control and automation technology as well as in the
energy and telecommunications sectors. With our large selection of actuators combined with the enormous choice of switch inserts, we can fulfil the requirements of all branches of industry.
These switches are characterised by their switching reliability, which explains why they are first choice
– especially in rugged operating conditions. All the components together form precise, well-engineered
limit switches that continue to open up new areas of application and ensure the operating safety of
technical plants.
Type key for SK and SM lines, standard designs
7
Technical specifications for sub-miniature switch SK, SM lines
Switch inserts …01… / …5... / …10… …4… / …8… …10…Z / …10…ZO
Switch type: 1 changeover contact switch 1 NC contact/1 NO contact 1 NC contact/1 NO contact / 2 NC contacts
Switching system: Snap-action mechanism Snap-action mechanism Slow-action mechanism
Contact material: Gold/Silver/Silver Gold/Silver Silver /Silver
Voltage: max. 250 VAC, 40-60Hz max. 250 VAC, 40-60Hz max. 250 VAC, 40-60Hz
Current capacity: max. 0.1A / 5A / 10A max. 4A / 8A max. 10A
Approvals: VDE, UL, CSA UL, CSA
Regulations: ASA sub-miniature switches are manufactured in accordance with the applicable
regulations IEC/EN 60204 and IEC/EN 60947-5-1
Design: Plastic-encapsulated stackable single limit switch, sub-miniature switch design, fastening
with screws M4, DIN 85 or central fastening attachment
Housing: Thermoplastic PA 6.6 glass fibre-reinforced
Connection: PVC control cable, structure corresponds with H05VV-F, grey RAL 7001, 3 x 0.5 mm2
or 4 x 0.5 mm2
, length 1m, longer or shorter cables as special designs,
special cables on request
Cable inlet: side or bottom with protective rubber sleeve
Protection class: IP 65 according to IEC/EN 60529, other protection classes on request
Plunger: Thermoplastic PA 6.6 glass fibre reinforced, stainless steel, nickel-plated brass
(depending on actuator design)
Sleeve: Neoprene oil-resistant
Lever actuator: nickel-plated, cold-rolled steel, stainless steel on request
Spring actuator: Stainless steel
Roller: Thermoplastic PA 6.6 glass fibre reinforced, sintered stainless steel, nickel-plated brass
(depending on actuator design)
Actuator travel: see type table
Actuating force: see type table
Installation position: optional
Switching cycles: min. 10 million
Working temperature: -20 °C to +80 °C
8
Sub-miniature switch SK
Type table for sub-miniature switch SK, standard selection
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SK 5 S 8022 0180 1 changeover
contact
5 1.00 side
SK 5 S U 8022 0181 5 1.00 bottom
SK 10 S 8022 0182 1 changeover
contact
10 2.00 side
SK 10 S U 8022 0183 10 2.00 bottom
SK 01 S 8022 0184 1 changeover
contact
0.1 1.60 side
SK 01 S U 8022 0185 0.1 1.60 bottom
SK 4 S 8022 0186 1 NC contact/
1 NO contact
4 2.00 side
SK 4 S U 8022 0187 4 2.00 bottom
SK 8 S 8022 0188 1 NC contact/
1 NO contact
8 2.20 side
SK 8 S U 8022 0189 8 2.20 bottom
Positive opening according to IEC/EN 60204 and IEC/EN 60947-5-1
SK 10 S Z 8022 0190 1 NC contact/
1 NO contact
10 3.30 side
SK 10 S U Z 8022 0191 10 3.30 bottom
SK 10 S ZO 8022 0568 2 NC contacts 10 3.30 side
SK 10 S U ZO 8022 0569 10 3.30 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SK 5 T17S 8022 0200 1 changeover
contact
5 1.00 side
SK 5 T17S U 8022 0201 5 1.00 bottom
SK 10 T17S 8022 0202 1 changeover
contact
10 2.00 side
SK 10 T17S U 8022 0203 10 2.00 bottom
SK 01 T17S 8022 0204 1 changeover
contact
0.1 1.60 side
SK 01 T17S U 8022 0205 0.1 1.60 bottom
SK 4 T17S 8022 0206 1 NC contact/
1 NO contact
4 2.00 side
SK 4 T17S U 8022 0207 4 2.00 bottom
SK 8 T17S 8022 0208 1 NC contact/
1 NO contact
8 2.20 side
SK 8 T17S U 8022 0209 8 2.20 bottom
Positive opening according to IEC/EN 60204 and IEC/EN 60947-5-1
SK 10 T17S Z 8022 0210 1 NC contact/
1 NO contact
10 3.30 side
SK 10 T17S UZ 8022 0211 10 3.30 bottom
SK 10 T17S ZO 8022 0570 2 NC contacts 10 3.30 side
SK 10T17SUZO 8022 0571 10 3.30 bottom
Approaching angle: max 20°, approaching speed: max 1 m/s
Approaching angle: max 20°, approaching speed: max 1 m/s
NEW
NEW
9
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SK 5 S 8022 0180 1 changeover
contact
5 1.00 side
SK 5 S U 8022 0181 5 1.00 bottom
SK 10 S 8022 0182 1 changeover
contact
10 2.00 side
SK 10 S U 8022 0183 10 2.00 bottom
SK 01 S 8022 0184 1 changeover
contact
0.1 1.60 side
SK 01 S U 8022 0185 0.1 1.60 bottom
SK 4 S 8022 0186 1 NC contact/
1 NO contact
4 2.00 side
SK 4 S U 8022 0187 4 2.00 bottom
SK 8 S 8022 0188 1 NC contact/
1 NO contact
8 2.20 side
SK 8 S U 8022 0189 8 2.20 bottom
Positive opening according to IEC/EN 60204 and IEC/EN 60947-5-1
SK 10 S Z 8022 0190 1 NC contact/
1 NO contact
10 3.30 side
SK 10 S U Z 8022 0191 10 3.30 bottom
SK 10 S ZO 8022 0568 2 NC contacts 10 3.30 side
SK 10 S U ZO 8022 0569 10 3.30 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SK 5 T17S 8022 0200 1 changeover
contact
5 1.00 side
SK 5 T17S U 8022 0201 5 1.00 bottom
SK 10 T17S 8022 0202 1 changeover
contact
10 2.00 side
SK 10 T17S U 8022 0203 10 2.00 bottom
SK 01 T17S 8022 0204 1 changeover
contact
0.1 1.60 side
SK 01 T17S U 8022 0205 0.1 1.60 bottom
SK 4 T17S 8022 0206 1 NC contact/
1 NO contact
4 2.00 side
SK 4 T17S U 8022 0207 4 2.00 bottom
SK 8 T17S 8022 0208 1 NC contact/
1 NO contact
8 2.20 side
SK 8 T17S U 8022 0209 8 2.20 bottom
Positive opening according to IEC/EN 60204 and IEC/EN 60947-5-1
SK 10 T17S Z 8022 0210 1 NC contact/
1 NO contact
10 3.30 side
SK 10 T17S UZ 8022 0211 10 3.30 bottom
SK 10 T17S ZO 8022 0570 2 NC contacts 10 3.30 side
SK 10T17SUZO 8022 0571 10 3.30 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SK 5 T21S 8022 0220 1 changeover
contact
5 1.00 side
SK 5 T21S U 8022 0221 5 1.00 bottom
SK 10 T21S 8022 0222 1 changeover
contact
10 2.00 side
SK 10 T21S U 8022 0223 10 2.00 bottom
SK 01 T21S 8022 0224 1 changeover
contact
0.1 1.60 side
SK 01 T21S U 8022 0225 0.1 1.60 bottom
SK 4 T21S 8022 0226 1 NC contact/
1 NO contact
4 2.00 side
SK 4 T21S U 8022 0227 4 2.00 bottom
SK 8 T21S 8022 0228 1 NC contact/
1 NO contact
8 2.20 side
SK 8 T21S U 8022 0229 8 2.20 bottom
Positive opening according to IEC/EN 60204 and IEC/EN 60947-5-1
SK 10 T21S Z 8022 0230 1 NC contact/
1 NO contact
10 3.30 side
SK 10 T21S UZ 8022 0231 10 3.30 bottom
SK 10 T21S ZO 8022 0572 2 NC contacts 10 3.30 side
SK 10T21SUZO 8022 0573 10 3.30 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SK 5 T24S 8022 0240 1 changeover
contact
5 1.00 side
SK 5 T24S U 8022 0241 5 1.00 bottom
SK 10 T24S 8022 0242 1 changeover
contact
10 2.00 side
SK 10 T24S U 8022 0243 10 2.00 bottom
SK 01 T24S 8022 0244 1 changeover
contact
0.1 1.60 side
SK 01 T24S U 8022 0245 0.1 1.60 bottom
SK 4 T24S 8022 0246 1 NC contact/
1 NO contact
4 2.00 side
SK 4 T24S U 8022 0247 4 2.00 bottom
SK 8 T24S 8022 0248 1 NC contact/
1 NO contact
8 2.20 side
SK 8 T24S U 8022 0249 8 2.20 bottom
Positive opening according to IEC/EN 60204 and IEC/EN 60947-5-1
SK 10 T24S Z 8022 0250 1 NC contact/
1 NO contact
10 3.30 side
SK 10 T24S UZ 8022 0251 10 3.30 bottom
SK 10 T24S Z 8022 0574 2 NC contacts 10 3.30 side
SK 10 T24S UZ 8022 0575 10 3.30 bottom
Approaching angle: max 20°, approaching speed: max 1 m/s
Approaching angle: max 20°, approaching speed: max 1 m/s
NEW
NEW
10
Sub-miniature switch SK
NEW
NEW
Type table for sub-miniature switch SK, standard selection
Approaching angle: max 20°, approaching speed: max 1 m/s
Approaching angle: max 20°, approaching speed: max 1 m/s
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SK 5 ZS 8022 0260 1 changeover
contact
5 1.00 side
SK 5 ZS U 8022 0261 5 1.00 bottom
SK 10 ZS 8022 0262 1 changeover
contact
10 2.00 side
SK 10 ZS U 8022 0263 10 2.00 bottom
SK 01 ZS 8022 0264 1 changeover
contact
0.1 1.60 side
SK 01 ZS U 8022 0265 0.1 1.60 bottom
SK 4 ZS 8022 0266 1 NC contact/
1 NO contact
4 2.00 side
SK 4 ZS U 8022 0267 4 2.00 bottom
SK 8 ZS 8022 0268 1 NC contact/
1 NO contact
8 2.20 side
SK 8 ZS U 8022 0269 8 2.20 bottom
Positive opening according to IEC/EN 60204 and IEC/EN 60947-5-1
SK 10 ZS Z 8022 0270 1 NC contact/
1 NO contact
10 3.30 side
SK 10 ZS UZ 8022 0271 10 3.30 bottom
SK 10 ZS ZO 8022 0576 2 NC contacts 10 3.30 side
SK 10 ZS UZO 8022 0577 10 3.30 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SK 5 ZTS 8022 0280 1 changeover
contact
5 1.00 side
SK 5 ZTS U 8022 0281 5 1.00 bottom
SK 10 ZTS 8022 0282 1 changeover
contact
10 2.00 side
SK 10 ZTS U 8022 0283 10 2.00 bottom
SK 01 ZTS 8022 0284 1 changeover
contact
0.1 1.60 side
SK 01 ZTS U 8022 0285 0.1 1.60 bottom
SK 4 ZTS 8022 0286 1 NC contact/
1 NO contact
4 2.00 side
SK 4 ZTS U 8022 0287 4 2.00 bottom
SK 8 ZTS 8022 0288 1 NC contact/
1 NO contact
8 2.20 side
SK 8 ZTS U 8022 0289 8 2.20 bottom
Positive opening according to IEC/EN 60204 and IEC/EN 60947-5-1
SK 10 ZTS Z 8022 0290 1 NC contact/
1 NO contact
10 3.30 side
SK 10 ZTS UZ 8022 0291 10 3.30 bottom
SK 10 ZTS Z 8022 0578 2 NC contacts 10 3.30 side
SK 10 ZTS UZ 8022 0579 10 3.30 bottom
11
NEW
NEW
Approaching angle: max 20°, approaching speed: max 1 m/s
Approaching angle: max 30°, approaching speed: max 3 m/s
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SK 5 ZS 8022 0260 1 changeover
contact
5 1.00 side
SK 5 ZS U 8022 0261 5 1.00 bottom
SK 10 ZS 8022 0262 1 changeover
contact
10 2.00 side
SK 10 ZS U 8022 0263 10 2.00 bottom
SK 01 ZS 8022 0264 1 changeover
contact
0.1 1.60 side
SK 01 ZS U 8022 0265 0.1 1.60 bottom
SK 4 ZS 8022 0266 1 NC contact/
1 NO contact
4 2.00 side
SK 4 ZS U 8022 0267 4 2.00 bottom
SK 8 ZS 8022 0268 1 NC contact/
1 NO contact
8 2.20 side
SK 8 ZS U 8022 0269 8 2.20 bottom
Positive opening according to IEC/EN 60204 and IEC/EN 60947-5-1
SK 10 ZS Z 8022 0270 1 NC contact/
1 NO contact
10 3.30 side
SK 10 ZS UZ 8022 0271 10 3.30 bottom
SK 10 ZS ZO 8022 0576 2 NC contacts 10 3.30 side
SK 10 ZS UZO 8022 0577 10 3.30 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SK 5 ZTS 8022 0280 1 changeover
contact
5 1.00 side
SK 5 ZTS U 8022 0281 5 1.00 bottom
SK 10 ZTS 8022 0282 1 changeover
contact
10 2.00 side
SK 10 ZTS U 8022 0283 10 2.00 bottom
SK 01 ZTS 8022 0284 1 changeover
contact
0.1 1.60 side
SK 01 ZTS U 8022 0285 0.1 1.60 bottom
SK 4 ZTS 8022 0286 1 NC contact/
1 NO contact
4 2.00 side
SK 4 ZTS U 8022 0287 4 2.00 bottom
SK 8 ZTS 8022 0288 1 NC contact/
1 NO contact
8 2.20 side
SK 8 ZTS U 8022 0289 8 2.20 bottom
Positive opening according to IEC/EN 60204 and IEC/EN 60947-5-1
SK 10 ZTS Z 8022 0290 1 NC contact/
1 NO contact
10 3.30 side
SK 10 ZTS UZ 8022 0291 10 3.30 bottom
SK 10 ZTS Z 8022 0578 2 NC contacts 10 3.30 side
SK 10 ZTS UZ 8022 0579 10 3.30 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SK 5 T26R 8022 0300 1 changeover
contact
5 1.00 side
SK 5 T26R U 8022 0301 5 1.00 bottom
SK 10 T26R 8022 0302 1 changeover
contact
10 2.00 side
SK 10 T26R U 8022 0303 10 2.00 bottom
SK 01 T26R 8022 0304 1 changeover
contact
0.1 1.60 side
SK 01 T26R U 8022 0305 0.1 1.60 bottom
SK 4 T26R 8022 0306 1 NC contact/
1 NO contact
4 2.00 side
SK 4 T26R U 8022 0307 4 2.00 bottom
SK 8 T26R 8022 0308 1 NC contact/
1 NO contact
8 2.20 side
SK 8 T26R U 8022 0309 8 2.20 bottom
Positive opening according to IEC/EN 60204 and IEC/EN 60947-5-1
SK 10 T26R Z 8022 0310 1 NC contact/
1 NO contact
10 3.30 side
SK 10 T26R U Z 8022 0311 10 3.30 bottom
SK 10 T26R Z 8022 0580 2 NC contacts 10 3.30 side
SK 10 T26R U Z 8022 0581 10 3.30 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SK 5 T26R90 8022 0320 1 changeover
contact
5 1.00 side
SK 5 T26R90 U 8022 0321 5 1.00 bottom
SK 10 T26R90 8022 0322 1 changeover
contact
10 2.00 side
SK 10 T26R90 U 8022 0323 10 2.00 bottom
SK 01T26R90 8022 0324 1 changeover
contact
0.1 1.60 side
SK 01 T26R90 U 8022 0325 0.1 1.60 bottom
SK 4 T26R90 8022 0326 1 NC contact/
1 NO contact
4 2.00 side
SK 4 T26R90 U 8022 0327 4 2.00 bottom
SK 8 T26R90 8022 0328 1 NC contact/
1 NO contact
8 2.20 side
SK 8 T26R90 U 8022 0329 8 2.20 bottom
Positive opening according to IEC/EN 60204 and IEC/EN 60947-5-1
SK 10 T26R90 Z 8022 0330 1 NC contact/
1 NO contact
10 3.30 side
SK 10 T26R90 U Z 8022 0331 10 3.30 bottom
SK 10 T26R90 Z 8022 0582 2 NC contacts 10 3.30 side
SK 10 T26R90 U Z 8022 0583 10 3.30 bottom
12
Sub-miniature switch SK
NEW
NEW
Type table for sub-miniature switch SK, standard selection
Approaching angle: max 30°, approaching speed: max 3 m/s
Approaching angle: max 30°, approaching speed: max 3 m/s
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SK 5 T33R 8022 0340 1 changeover
contact
5 1.00 side
SK 5 T33R U 8022 0341 5 1.00 bottom
SK 10 T33R 8022 0342 1 changeover
contact
10 2.00 side
SK 10 T33R U 8022 0343 10 2.00 bottom
SK 01 T33R 8022 0344 1 changeover
contact
0.1 1.60 side
SK 01 T33R U 8022 0345 0.1 1.60 bottom
SK 4 T33R 8022 0346 1 NC contact/
1 NO contact
4 2.00 side
SK 4 T33R U 8022 0347 4 2.00 bottom
SK 8 T33R 8022 0348 1 NC contact/
1 NO contact
8 2.20 side
SK 8 T33R U 8022 0349 8 2.20 bottom
Positive opening according to IEC/EN 60204 and IEC/EN 60947-5-1
SK 10 T33R Z 8022 0350 1 NC contact/
1 NO contact
10 3.30 side
SK 10 T33R U Z 8022 0351 10 3.30 bottom
SK 10 T33R ZO 8022 0584 2 NC contacts 10 3.30 side
SK 10 T33R U ZO 8022 0585 10 3.30 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SK 5 T33R90 8022 0360 1 changeover
contact
5 1.00 side
SK 5 T33R90 U 8022 0361 5 1.00 bottom
SK 10 T33R90 S 8022 0362 1 changeover
contact
10 2.00 side
SK 10 T33R90 U 8022 0363 10 2.00 bottom
SK 01 T33R90 8022 0364 1 changeover
contact
0.1 1.60 side
SK 01 T33R90 U 8022 0365 0.1 1.60 bottom
SK 4 T33R90 8022 0366 1 NC contact/
1 NO contact
4 2.00 side
SK 4 T33R90 U 8022 0367 4 2.00 bottom
SK 8 T33R90 8022 0368 1 NC contact/
1 NO contact
8 2.20 side
SK 8 T33R90 U 8022 0369 8 2.20 bottom
Positive opening according to IEC/EN 60204 and IEC/EN 60947-5-1
SK 10 T33R90 Z 8022 0370 1 NC contact/
1 NO contact
10 3.30 side
SK 10T33R90 UZ 8022 0371 10 3.30 bottom
SK 10 T33R90 ZO 8022 0586 2 NC contacts 10 3.30 side
SK 10T33R90 UZO 8022 0587 10 3.30 bottom
13
NEW
NEW
Approaching angle: max 30°, approaching speed: max 3 m/s
Approaching angle: max 30°, approaching speed: max 3 m/s
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SK 5 T33R 8022 0340 1 changeover
contact
5 1.00 side
SK 5 T33R U 8022 0341 5 1.00 bottom
SK 10 T33R 8022 0342 1 changeover
contact
10 2.00 side
SK 10 T33R U 8022 0343 10 2.00 bottom
SK 01 T33R 8022 0344 1 changeover
contact
0.1 1.60 side
SK 01 T33R U 8022 0345 0.1 1.60 bottom
SK 4 T33R 8022 0346 1 NC contact/
1 NO contact
4 2.00 side
SK 4 T33R U 8022 0347 4 2.00 bottom
SK 8 T33R 8022 0348 1 NC contact/
1 NO contact
8 2.20 side
SK 8 T33R U 8022 0349 8 2.20 bottom
Positive opening according to IEC/EN 60204 and IEC/EN 60947-5-1
SK 10 T33R Z 8022 0350 1 NC contact/
1 NO contact
10 3.30 side
SK 10 T33R U Z 8022 0351 10 3.30 bottom
SK 10 T33R ZO 8022 0584 2 NC contacts 10 3.30 side
SK 10 T33R U ZO 8022 0585 10 3.30 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SK 5 T33R90 8022 0360 1 changeover
contact
5 1.00 side
SK 5 T33R90 U 8022 0361 5 1.00 bottom
SK 10 T33R90 S 8022 0362 1 changeover
contact
10 2.00 side
SK 10 T33R90 U 8022 0363 10 2.00 bottom
SK 01 T33R90 8022 0364 1 changeover
contact
0.1 1.60 side
SK 01 T33R90 U 8022 0365 0.1 1.60 bottom
SK 4 T33R90 8022 0366 1 NC contact/
1 NO contact
4 2.00 side
SK 4 T33R90 U 8022 0367 4 2.00 bottom
SK 8 T33R90 8022 0368 1 NC contact/
1 NO contact
8 2.20 side
SK 8 T33R90 U 8022 0369 8 2.20 bottom
Positive opening according to IEC/EN 60204 and IEC/EN 60947-5-1
SK 10 T33R90 Z 8022 0370 1 NC contact/
1 NO contact
10 3.30 side
SK 10T33R90 UZ 8022 0371 10 3.30 bottom
SK 10 T33R90 ZO 8022 0586 2 NC contacts 10 3.30 side
SK 10T33R90 UZO 8022 0587 10 3.30 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SK 5 ZTR 8022 0380 1 changeover
contact
5 1.00 side
SK 5 ZTR U 8022 0381 5 1.00 bottom
SK 10 ZTR 8022 0382 1 changeover
contact
10 2.00 side
SK 10 ZTR U 8022 0383 10 2.00 bottom
SK 01 ZTR 8022 0384 1 changeover
contact
0.1 1.60 side
SK 01 ZTR U 8022 0385 0.1 1.60 bottom
SK 4 ZTR 8022 0386 1 NC contact/
1 NO contact
4 2.00 side
SK 4 ZTR U 8022 0387 4 2.00 bottom
SK 8 ZTR 8022 0388 1 NC contact/
1 NO contact
8 2.20 side
SK 8 ZTR U 8022 0389 8 2.20 bottom
Positive opening according to IEC/EN 60204 and IEC/EN 60947-5-1
SK 10 ZTR Z 8022 0390 1 NC contact/
1 NO contact
10 3.30 side
SK 10 ZTR U Z 8022 0391 10 3.30 bottom
SK 10 ZTR ZO 8022 0588 2 NC contacts 10 3.30 side
SK 10 ZTR U ZO 8022 0589 10 3.30 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SK 5 ZTR90 8022 0400 1 changeover
contact
5 1.00 side
SK 5 ZTR90 U 8022 0401 5 1.00 bottom
SK 10 ZTR90 8022 0402 1 changeover
contact
10 2.00 side
SK 10 ZTR90 U 8022 0403 10 2.00 bottom
SK 01 ZTR90 8022 0404 1 changeover
contact
0.1 1.60 side
SK 01 ZTR90 U 8022 0405 0.1 1.60 bottom
SK 4 ZTR90 8022 0406 1 NC contact/
1 NO contact
4 2.00 side
SK 4 ZTR90 U 8022 0407 4 2.00 bottom
SK 8 ZTR90 8022 0408 1 NC contact/
1 NO contact
8 2.20 side
SK 8 ZTR90 U 8022 0409 8 2.20 bottom
Positive opening according to IEC/EN 60204 and IEC/EN 60947-5-1
SK 10 ZTR90 Z 8022 0410 1 NC contact/
1 NO contact
10 3.30 side
SK 10 ZTR90 U Z 8022 0411 10 3.30 bottom
SK 10 ZTR90 ZO 8022 0590 2 NC contacts 10 3.30 side
SK 10 ZTR90 UZO 8022 0591 10 3.30 bottom
14
Sub-miniature switch SM
NEW
NEW
Type table for sub-miniature switch SM, standard selection
Approaching angle: max 20°, approaching speed: max 1 m/s
Approaching angle: max 20°, approaching speed: max 1 m/s
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SM 5 S 8022 0000 1 changeover
contact
5 1.00 side
SM 5 S U 8022 0001 5 1.00 bottom
SM 10 S 8022 0002 1 changeover
contact
10 2.00 side
SM 10 S U 8022 0003 10 2.00 bottom
SM 01 S 8022 0172 1 changeover
contact
0.1 1.60 side
SM 01 S U 8022 0173 0.1 1.60 bottom
SM 4 S 8022 0174 1 NC contact/
1 NO contact
4 2.00 side
SM 4 S U 8022 0175 4 2.00 bottom
SM 8 S 8022 0176 1 NC contact/
1 NO contact
8 2.20 side
SM 8 S U 8022 0177 8 2.20 bottom
Positive opening according to IEC/EN 60204 and IEC/EN 60947-5-1
SM 10 S Z 8022 0178 1 NC contact/
1 NO contact
10 3.30 side
SM 10 S U Z 8022 0179 10 3.30 bottom
SM 10 S ZO 8022 0592 2 NC contacts 10 3.30 side
SM 10 S U ZO 8022 0593 10 3.30 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SM 5 T17S 8022 0120 1 changeover
contact
5 1.00 side
SM 5 T17S U 8022 0121 5 1.00 bottom
SM 10 T17S 8022 0122 1 changeover
contact
10 2.00 side
SM 10 T17S U 8022 0123 10 2.00 bottom
SM 01 T17S 8022 0192 1 changeover
contact
0.1 1.60 side
SM 01 T17S U 8022 0193 0.1 1.60 bottom
SM 4 T17S 8022 0194 1 NC contact/
1 NO contact
4 2.00 side
SM 4 T17S U 8022 0195 4 2.00 bottom
SM 8 T17S 8022 0196 1 NC contact/
1 NO contact
8 2.20 side
SM 8 T17S U 8022 0197 8 2.20 bottom
Positive opening according to IEC/EN 60204 and IEC/EN 60947-5-1
SM 10 T17S Z 8022 0198 1 NC contact/
1 NO contact
10 3.30 side
SM 10 T17S UZ 8022 0199 10 3.30 bottom
SM 10 T17S ZO 8022 0594 2 NC contacts 10 3.30 side
SM 10T17SUZO 8022 0595 10 3.30 bottom
15
NEW
NEW
Approaching angle: max 20°, approaching speed: max 1 m/s
Approaching angle: max 20°, approaching speed: max 1 m/s
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SM 5 S 8022 0000 1 changeover
contact
5 1.00 side
SM 5 S U 8022 0001 5 1.00 bottom
SM 10 S 8022 0002 1 changeover
contact
10 2.00 side
SM 10 S U 8022 0003 10 2.00 bottom
SM 01 S 8022 0172 1 changeover
contact
0.1 1.60 side
SM 01 S U 8022 0173 0.1 1.60 bottom
SM 4 S 8022 0174 1 NC contact/
1 NO contact
4 2.00 side
SM 4 S U 8022 0175 4 2.00 bottom
SM 8 S 8022 0176 1 NC contact/
1 NO contact
8 2.20 side
SM 8 S U 8022 0177 8 2.20 bottom
Positive opening according to IEC/EN 60204 and IEC/EN 60947-5-1
SM 10 S Z 8022 0178 1 NC contact/
1 NO contact
10 3.30 side
SM 10 S U Z 8022 0179 10 3.30 bottom
SM 10 S ZO 8022 0592 2 NC contacts 10 3.30 side
SM 10 S U ZO 8022 0593 10 3.30 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SM 5 T17S 8022 0120 1 changeover
contact
5 1.00 side
SM 5 T17S U 8022 0121 5 1.00 bottom
SM 10 T17S 8022 0122 1 changeover
contact
10 2.00 side
SM 10 T17S U 8022 0123 10 2.00 bottom
SM 01 T17S 8022 0192 1 changeover
contact
0.1 1.60 side
SM 01 T17S U 8022 0193 0.1 1.60 bottom
SM 4 T17S 8022 0194 1 NC contact/
1 NO contact
4 2.00 side
SM 4 T17S U 8022 0195 4 2.00 bottom
SM 8 T17S 8022 0196 1 NC contact/
1 NO contact
8 2.20 side
SM 8 T17S U 8022 0197 8 2.20 bottom
Positive opening according to IEC/EN 60204 and IEC/EN 60947-5-1
SM 10 T17S Z 8022 0198 1 NC contact/
1 NO contact
10 3.30 side
SM 10 T17S UZ 8022 0199 10 3.30 bottom
SM 10 T17S ZO 8022 0594 2 NC contacts 10 3.30 side
SM 10T17SUZO 8022 0595 10 3.30 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SM 5 T21S 8022 0124 1 changeover
contact
5 1.00 side
SM 5 T21S U 8022 0125 5 1.00 bottom
SM 10 T21S 8022 0126 1 changeover
contact
10 2.00 side
SM 10 T21S U 8022 0127 10 2.00 bottom
SM 01 T21S 8022 0212 1 changeover
contact
0.1 1.60 side
SM 01 T21S U 8022 0213 0.1 1.60 bottom
SM 4 T21S 8022 0214 1 NC contact/
1 NO contact
4 2.00 side
SM 4 T21S U 8022 0215 4 2.00 bottom
SM 8 T21S 8022 0216 1 NC contact/
1 NO contact
8 2.20 side
SM 8 T21S U 8022 0217 8 2.20 bottom
Positive opening according to IEC/EN 60204 and IEC/EN 60947-5-1
SM 10 T21S Z 8022 0218 1 NC contact/
1 NO contact
10 3.30 side
SM 10T21SUZ 8022 0219 10 3.30 bottom
SM 10 T21S ZO 8022 0596 2 NC contacts 10 3.30 side
SM 10T21SUZO 8022 0597 10 3.30 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SM 5 T24S 8022 0144 1 changeover
contact
5 1.00 side
SM 5 T24S U 8022 0145 5 1.00 bottom
SM 10 T24S 8022 0146 1 changeover
contact
10 2.00 side
SM 10 T24S U 8022 0147 10 2.00 bottom
SM 01 T24S 8022 0232 1 changeover
contact
0.1 1.60 side
SM 01 T24S U 8022 0233 0.1 1.60 bottom
SM 4 T24S 8022 0234 1 NC contact/
1 NO contact
4 2.00 side
SM 4 T24S U 8022 0235 4 2.00 bottom
SM 8 T24S 8022 0236 1 NC contact/
1 NO contact
8 2.20 side
SM 8 T24S U 8022 0237 8 2.20 bottom
Positive opening according to IEC/EN 60204 and IEC/EN 60947-5-1
SM 10 T24S Z 8022 0238 1 NC contact/
1 NO contact
10 3.30 side
SM 10 T24S UZ 8022 0239 10 3.30 bottom
SM 10 T24S ZO 8022 0598 2 NC contacts 10 3.30 side
SM 10T24SUZO 8022 0599 10 3.30 bottom
16
Sub-miniature switch SM
NEW
NEW
Type table for sub-miniature switch SM, standard selection
Approaching angle: max 20°, approaching speed: max 1 m/s
Approaching angle: max 20°, approaching speed: max 1 m/s
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SM 5 ZS 8022 0028 1 changeover
contact
5 1.00 side
SM 5 ZS U 8022 0029 5 1.00 bottom
SM 10 ZS 8022 0030 1 changeover
contact
10 2.00 side
SM 10 ZS U 8022 0031 10 2.00 bottom
SM 01 ZS 8022 0252 1 changeover
contact
0.1 1.60 side
SM 01 ZS U 8022 0253 0.1 1.60 bottom
SM 4 ZS 8022 0254 1 NC contact/
1 NO contact
4 2.00 side
SM 4 ZS U 8022 0255 4 2.00 bottom
SM 8 ZS 8022 0256 1 NC contact/
1 NO contact
8 2.20 side
SM 8 ZS U 8022 0257 8 2.20 bottom
Positive opening according to IEC/EN 60204 and IEC/EN 60947-5-1
SM 10 ZS Z 8022 0258 1 NC contact/
1 NO contact
10 3.30 side
SM 10 ZS UZ 8022 0259 10 3.30 bottom
SM 10 ZS ZO 8022 0600 2 NC contacts 10 3.30 side
SM 10 ZS UZO 8022 0601 10 3.30 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SM 5 ZTS 8022 0084 1 changeover
contact
5 1.00 side
SM 5 ZTS U 8022 0085 5 1.00 bottom
SM 10 ZTS 8022 0086 1 changeover
contact
10 2.00 side
SM 10 ZTS U 8022 0087 10 2.00 bottom
SM 01 ZTS 8022 0272 1 changeover
contact
0.1 1.60 side
SM 01 ZTS U 8022 0273 0.1 1.60 bottom
SM 4 ZTS 8022 0274 1 NC contact/
1 NO contact
4 2.00 side
SM 4 ZTS U 8022 0275 4 2.00 bottom
SM 8 ZTS 8022 0276 1 NC contact/
1 NO contact
8 2.20 side
SM 8 ZTS U 8022 0277 8 2.20 bottom
Positive opening according to IEC/EN 60204 and IEC/EN 60947-5-1
SM 10 ZTS Z 8022 0278 1 NC contact/
1 NO contact
10 3.30 side
SM 10 ZTS UZ 8022 0279 10 3.30 bottom
SM 10 ZTS ZO 8022 0602 2 NC contacts 10 3.30 side
SM 10ZTSUZO 8022 0603 10 3.30 bottom
17
NEW
NEW
Approaching angle: max 30°, approaching speed: max 3 m/s
Approaching angle: max 30°, approaching speed: max 3 m/s
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SM 5 ZS 8022 0028 1 changeover
contact
5 1.00 side
SM 5 ZS U 8022 0029 5 1.00 bottom
SM 10 ZS 8022 0030 1 changeover
contact
10 2.00 side
SM 10 ZS U 8022 0031 10 2.00 bottom
SM 01 ZS 8022 0252 1 changeover
contact
0.1 1.60 side
SM 01 ZS U 8022 0253 0.1 1.60 bottom
SM 4 ZS 8022 0254 1 NC contact/
1 NO contact
4 2.00 side
SM 4 ZS U 8022 0255 4 2.00 bottom
SM 8 ZS 8022 0256 1 NC contact/
1 NO contact
8 2.20 side
SM 8 ZS U 8022 0257 8 2.20 bottom
Positive opening according to IEC/EN 60204 and IEC/EN 60947-5-1
SM 10 ZS Z 8022 0258 1 NC contact/
1 NO contact
10 3.30 side
SM 10 ZS UZ 8022 0259 10 3.30 bottom
SM 10 ZS ZO 8022 0600 2 NC contacts 10 3.30 side
SM 10 ZS UZO 8022 0601 10 3.30 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SM 5 ZTS 8022 0084 1 changeover
contact
5 1.00 side
SM 5 ZTS U 8022 0085 5 1.00 bottom
SM 10 ZTS 8022 0086 1 changeover
contact
10 2.00 side
SM 10 ZTS U 8022 0087 10 2.00 bottom
SM 01 ZTS 8022 0272 1 changeover
contact
0.1 1.60 side
SM 01 ZTS U 8022 0273 0.1 1.60 bottom
SM 4 ZTS 8022 0274 1 NC contact/
1 NO contact
4 2.00 side
SM 4 ZTS U 8022 0275 4 2.00 bottom
SM 8 ZTS 8022 0276 1 NC contact/
1 NO contact
8 2.20 side
SM 8 ZTS U 8022 0277 8 2.20 bottom
Positive opening according to IEC/EN 60204 and IEC/EN 60947-5-1
SM 10 ZTS Z 8022 0278 1 NC contact/
1 NO contact
10 3.30 side
SM 10 ZTS UZ 8022 0279 10 3.30 bottom
SM 10 ZTS ZO 8022 0602 2 NC contacts 10 3.30 side
SM 10ZTSUZO 8022 0603 10 3.30 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SM 5 T26R 8022 0128 1 changeover
contact
5 1.00 side
SM 5 T26R U 8022 0129 5 1.00 bottom
SM 10 T26R 8022 0130 1 changeover
contact
10 2.00 side
SM 10 T26R U 8022 0131 10 2.00 bottom
SM 01 T26R 8022 0292 1 changeover
contact
0.1 1.60 side
SM 01 T26R U 8022 0293 0.1 1.60 bottom
SM 4 T26R 8022 0294 1 NC contact/
1 NO contact
4 2.00 side
SM 4 T26R U 8022 0295 4 2.00 bottom
SM 8 T26R 8022 0296 1 NC contact/
1 NO contact
8 2.20 side
SM 8 T26R U 8022 0297 8 2.20 bottom
Positive opening according to IEC/EN 60204 and IEC/EN 60947-5-1
SM 10 T26R Z 8022 0298 1 NC contact/
1 NO contact
10 3.30 side
SM 10 T26R U Z 8022 0299 10 3.30 bottom
SM 10 T26R ZO 8022 0604 2 NC contacts 10 3.30 side
SM 10 T26R U ZO 8022 0605 10 3.30 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SM 5 T26R90 8022 0132 1 changeover
contact
5 1.00 side
SM 5 T26R90 U 8022 0133 5 1.00 bottom
SM 10 T26R90 8022 0134 1 changeover
contact
10 2.00 side
SM 10 T26R90 U 8022 0135 10 2.00 bottom
SM 01T26R90 8022 0312 1 changeover
contact
0.1 1.60 side
SM 01 T26R90 U 8022 0313 0.1 1.60 bottom
SM 4 T26R90 8022 0314 1 NC contact/
1 NO contact
4 2.00 side
SM 4 T26R90 U 8022 0315 4 2.00 bottom
SM 8 T26R90 8022 0316 1 NC contact/
1 NO contact
8 2.20 side
SM 8 T26R90 U 8022 0317 8 2.20 bottom
Positive opening according to IEC/EN 60204 and IEC/EN 60947-5-1
SM 10 T26R90 Z 8022 0318 1 NC contact/
1 NO contact
10 3.30 side
SM 10 T26R90 U Z 8022 0319 10 3.30 bottom
SM 10 T26R90 Z 8022 0606 2 NC contacts 10 3.30 side
SM 10 T26R90 U Z 8022 0607 10 3.30 bottom
18
Sub-miniature switch SM
NEW
NEW
Type table for sub-miniature switch SM, standard selection
Approaching angle: max 30°, approaching speed: max 3 m/s
Approaching angle: max 30°, approaching speed: max 3 m/s
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SM 5 T33R 8022 0136 1 changeover
contact
5 1.00 side
SM 5 T33R U 8022 0137 5 1.00 bottom
SM 10 T33R 8022 0138 1 changeover
contact
10 2.00 side
SM 10 T33R U 8022 0139 10 2.00 bottom
SM 01 T33R 8022 0332 1 changeover
contact
0.1 1.60 side
SM 01 T33R U 8022 0332 0.1 1.60 bottom
SM 4 T33R 8022 0334 1 NC contact/
1 NO contact
4 2.00 side
SM 4 T33R U 8022 0335 4 2.00 bottom
SM 8 T33R 8022 0336 1 NC contact/
1 NO contact
8 2.20 side
SM 8 T33R U 8022 0337 8 2.20 bottom
Positive opening according to IEC/EN 60204 and IEC/EN 60947-5-1
SM 10 T33R Z 8022 0338 1 NC contact/
1 NO contact
10 3.30 side
SK 10 T33R U Z 8022 0339 10 3.30 bottom
SM 10 T33R ZO 8022 0608 2 NC contacts 10 3.30 side
SK 10 T33R U ZO 8022 0609 10 3.30 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SM 5 T33R90 8022 0140 1 changeover
contact
5 1.00 side
SM 5 T33R90 U 8022 0141 5 1.00 bottom
SM 10 T33R90 S 8022 0142 1 changeover
contact
10 2.00 side
SM 10 T33R90 U 8022 0143 10 2.00 bottom
SM 01 T33R90 8022 0352 1 changeover
contact
0.1 1.60 side
SM 01 T33R90 U 8022 0353 0.1 1.60 bottom
SM 4 T33R90 8022 0354 1 NC contact/
1 NO contact
4 2.00 side
SM 4 T33R90 U 8022 0355 4 2.00 bottom
SM 8 T33R90 8022 0356 1 NC contact/
1 NO contact
8 2.20 side
SM 8 T33R90 U 8022 0357 8 2.20 bottom
Positive opening according to IEC/EN 60204 and IEC/EN 60947-5-1
SM 10 T33R90 Z 8022 0358 1 NC contact/
1 NO contact
10 3.30 side
SM 10T33R90 UZ 8022 0359 10 3.30 bottom
SM 10 T33R90 ZO 8022 0610 2 NC contacts 10 3.30 side
SM 10T33R90 UZO 8022 0611 10 3.30 bottom
19
NEW
NEW
Approaching angle: max 30°, approaching speed: max 3 m/s
Approaching angle: max 30°, approaching speed: max 3 m/s
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SM 5 ZTR 8022 0088 1 changeover
contact
5 1.00 side
SM 5 ZTR U 8022 0089 5 1.00 bottom
SM 10 ZTR 8022 0090 1 changeover
contact
10 2.00 side
SM 10 ZTR U 8022 0091 10 2.00 bottom
SM 01 ZTR 8022 0372 1 changeover
contact
0.1 1.60 side
SM 01 ZTR U 8022 0373 0.1 1.60 bottom
SM 4 ZTR 8022 0374 1 NC contact/
1 NO contact
4 2.00 side
SM 4 ZTR U 8022 0375 4 2.00 bottom
SM 8 ZTR 8022 0376 1 NC contact/
1 NO contact
8 2.20 side
SM 8 ZTR U 8022 0377 8 2.20 bottom
Positive opening according to IEC/EN 60204 and IEC/EN 60947-5-1
SM 10 ZTR Z 8022 0378 1 NC contact/
1 NO contact
10 3.30 side
SM 10 ZTR U Z 8022 0379 10 3.30 bottom
SM 10 ZTR ZO 8022 0612 2 NC contacts 10 3.30 side
SM 10 ZTR U ZO 8022 0613 10 3.30 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SM 5 ZTR90 8022 0092 1 changeover
contact
5 1.00 side
SM 5 ZTR90 U 8022 0093 5 1.00 bottom
SM 10 ZTR90 8022 0094 1 changeover
contact
10 2.00 side
SM 10 ZTR90 U 8022 0095 10 2.00 bottom
SM 01 ZTR90 8022 0392 1 changeover
contact
0.1 1.60 side
SM 01 ZTR90 U 8022 0393 0.1 1.60 bottom
SM 4 ZTR90 8022 0394 1 NC contact/
1 NO contact
4 2.00 side
SM 4 ZTR90 U 8022 0395 4 2.00 bottom
SM 8 ZTR90 8022 0396 1 NC contact/
1 NO contact
8 2.20 side
SM 8 ZTR90 U 8022 0397 8 2.20 bottom
Positive opening according to IEC/EN 60204 and IEC/EN 60947-5-1
SM 10 ZTR90 Z 8022 0398 1 NC contact/
1 NO contact
10 3.30 side
SM 10 ZTR90 U Z 8022 0399 10 3.30 bottom
SM 10 ZTR90 ZO 8022 0614 2 NC contacts 10 3.30 side
SM 10 ZTR90 U ZO 8022 0615 10 3.30 bottom
20
Sub-miniature switch SM
Type table for sub-miniature switch SM, standard selection
Approaching angle: max 30°, approaching speed: max 3 m/s
Approaching angle: max 30°, approaching speed: max 3 m/s
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SM 5 K12 8022 0004 1 changeover
contact
5 0.80 side
SM 5 K12 U 8022 0005 5 0.80 bottom
SM 10 K12 8022 0006 1 changeover
contact
10 1.90 side
SM 10 K12 U 8022 0007 10 1.90 bottom
SM 01 K12 8022 0412 1 changeover
contact
0.1 1.70 side
SM 01 K12 U 8022 0413 0.1 1.70 bottom
SM 4 K12 8022 0414 1 NC contact/
1 NO contact
4 1.90 side
SM 4 K12 U 8022 0415 4 1.90 bottom
SM 8 K12 8022 0416 1 NC contact/
1 NO contact
8 1.80 side
SM 8 K12 U 8022 0417 8 1.80 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SM 5 K27 8022 0008 1 changeover
contact
5 0.40 side
SM 5 K27 U 8022 0009 5 0.40 bottom
SM 10 K27 8022 0010 1 changeover
contact
10 0.85 side
SM 10 K27 U 8022 0011 10 0.85 bottom
SM 01 K27 8022 0418 1 changeover
contact
0.1 0.70 side
SM 01 K27 U 8022 0419 0.1 0.70 bottom
SM 4 K27 8022 0420 1 NC contact/
1 NO contact
4 0.80 side
SM 4 K27 U 8022 0421 4 0.80 bottom
SM 8 K27 8022 0422 1 NC contact/
1 NO contact
8 0.90 side
SM 8 K27 U 8022 0423 8 0.90 bottom
21
NEW
Approaching angle: max 30°, approaching speed: max 3 m/s
Approaching angle: max 30°, approaching speed: max 3 m/s
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SM 5 K12 8022 0004 1 changeover
contact
5 0.80 side
SM 5 K12 U 8022 0005 5 0.80 bottom
SM 10 K12 8022 0006 1 changeover
contact
10 1.90 side
SM 10 K12 U 8022 0007 10 1.90 bottom
SM 01 K12 8022 0412 1 changeover
contact
0.1 1.70 side
SM 01 K12 U 8022 0413 0.1 1.70 bottom
SM 4 K12 8022 0414 1 NC contact/
1 NO contact
4 1.90 side
SM 4 K12 U 8022 0415 4 1.90 bottom
SM 8 K12 8022 0416 1 NC contact/
1 NO contact
8 1.80 side
SM 8 K12 U 8022 0417 8 1.80 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SM 5 K27 8022 0008 1 changeover
contact
5 0.40 side
SM 5 K27 U 8022 0009 5 0.40 bottom
SM 10 K27 8022 0010 1 changeover
contact
10 0.85 side
SM 10 K27 U 8022 0011 10 0.85 bottom
SM 01 K27 8022 0418 1 changeover
contact
0.1 0.70 side
SM 01 K27 U 8022 0419 0.1 0.70 bottom
SM 4 K27 8022 0420 1 NC contact/
1 NO contact
4 0.80 side
SM 4 K27 U 8022 0421 4 0.80 bottom
SM 8 K27 8022 0422 1 NC contact/
1 NO contact
8 0.90 side
SM 8 K27 U 8022 0423 8 0.90 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SM 5 K60 8022 0012 1 changeover
contact
5 0.20 side
SM 5 K60 U 8022 0013 5 0.20 bottom
SM 10 K60 8022 0014 1 changeover
contact
10 0.40 side
SM 10 K60 U 8022 0015 10 0.40 bottom
SM 01 K60 8022 0424 1 changeover
contact
0.1 0.30 side
SM 01 K60 U 8022 0425 0.1 0.30 bottom
SM 4 K60 8022 0426 1 NC contact/
1 NO contact
4 0.40 side
SM 4 K60 U 8022 0427 4 0.40 bottom
SM 8 K60 8022 0428 1 NC contact/
1 NO contact
8 0.45 side
SM 8 K60 U 8022 0429 8 0.45 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SM 5 G38G 8022 0096 1 changeover
contact
5 0.60 side
SM 5 G38G U 8022 0097 5 0.60 bottom
SM 10 G38G 8022 0098 1 changeover
contact
10 1.10 side
SM 10 G38G U 8022 0099 10 1.10 bottom
SM 01 G38G 8022 0430 1 changeover
contact
0.1 0.80 side
SM 01 G38G U 8022 0431 0.1 0.80 bottom
SM 4 G38G 8022 0432 1 NC contact/
1 NO contact
4 1.45 side
SM 4 G38G U 8022 0433 4 1.45 bottom
SM 8 G38G 8022 0434 1 NC contact/
1 NO contact
8 1.50 side
SM 8 G38G U 8022 0435 8 1.50 bottom
Positive opening according to IEC/EN 60204 and IEC/EN 60947-5-1
SM 10 G38G Z 8022 0436 1 NC contact/
1 NO contact
10 2.50 side
SM 10 G38G U Z 8022 0437 10 2.50 bottom
SM 10 G38G ZO 8022 0616 2 NC contacts 10 2.50 side
SM 10 G38G U ZO 8022 0617 10 2.50 bottom
22
Sub-miniature switch SM
Type table for sub-miniature switch SM, standard selection
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SM 5 G50G 8022 0032 1 changeover
contact
5 0.40 side
SM 5 G50G U 8022 0033 5 0.40 bottom
SM 10 G50G 8022 0034 1 changeover
contact
10 0.85 side
SM 10 G50G U 8022 0035 10 0.85 bottom
SM 01 G50G 8022 0438 1 changeover
contact
0.1 0.70 side
SM 01 G50G U 8022 0439 0.1 0.70 bottom
SM 4 G50G 8022 0440 1 NC contact/
1 NO contact
4 0.70 side
SM 4 G50G U 8022 0441 4 0.70 bottom
SM 8 G50G 8022 0442 1 NC contact/
1 NO contact
8 0.75 side
SM 8 G50G U 8022 0443 8 0.75 bottom
Positive opening according to IEC/EN 60204 and IEC/EN 60947-5-1
SM 10 G50G Z 8022 0444 1 NC contact/
1 NO contact
10 1.60 side
SM 10 G50G U Z 8022 0445 10 1.60 bottom
SM 10 G50G ZO 8022 0618 2 NC contacts 10 1.60 side
SM 10 G50G U ZO 8022 0619 10 1.60 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SM 5 G70G 8022 0036 1 changeover
contact
5 0.30 side
SM 5 G70G U 8022 0037 5 0.30 bottom
SM 10 G70G 8022 0038 1 changeover
contact
10 0.55 side
SM 10 G70G U 8022 0039 10 0.55 bottom
SM 01 G70G 8022 0446 1 changeover
contact
0.1 0.45 side
SM 01 G70G U 8022 0447 0.1 0.45 bottom
SM 4 G70G 8022 0448 1 NC contact/
1 NO contact
4 0.55 side
SM 4 G70G U 8022 0449 4 0.55 bottom
SM 8 G70G 8022 0450 1 NC contact/
1 NO contact
8 0.60 side
SM 8 G70G U 8022 0451 8 0.60 bottom
Positive opening according to IEC/EN 60204 and IEC/EN 60947-5-1
SM 10 G70G Z 8022 0452 1 NC contact/
1 NO contact
10 1.05 side
SM 10 G70G U Z 8022 0453 10 1.05 bottom
SM 10 G70G ZO 8022 0620 2 NC contacts 10 1.05 side
SM 10 G70G U ZO 8022 0621 10 1.05 bottom
NEW
NEW
Approaching angle: max 30°, approaching speed: max 3 m/s
Approaching angle: max 30°, approaching speed: max 3 m/s
23
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SM 5 G50G 8022 0032 1 changeover
contact
5 0.40 side
SM 5 G50G U 8022 0033 5 0.40 bottom
SM 10 G50G 8022 0034 1 changeover
contact
10 0.85 side
SM 10 G50G U 8022 0035 10 0.85 bottom
SM 01 G50G 8022 0438 1 changeover
contact
0.1 0.70 side
SM 01 G50G U 8022 0439 0.1 0.70 bottom
SM 4 G50G 8022 0440 1 NC contact/
1 NO contact
4 0.70 side
SM 4 G50G U 8022 0441 4 0.70 bottom
SM 8 G50G 8022 0442 1 NC contact/
1 NO contact
8 0.75 side
SM 8 G50G U 8022 0443 8 0.75 bottom
Positive opening according to IEC/EN 60204 and IEC/EN 60947-5-1
SM 10 G50G Z 8022 0444 1 NC contact/
1 NO contact
10 1.60 side
SM 10 G50G U Z 8022 0445 10 1.60 bottom
SM 10 G50G ZO 8022 0618 2 NC contacts 10 1.60 side
SM 10 G50G U ZO 8022 0619 10 1.60 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SM 5 G70G 8022 0036 1 changeover
contact
5 0.30 side
SM 5 G70G U 8022 0037 5 0.30 bottom
SM 10 G70G 8022 0038 1 changeover
contact
10 0.55 side
SM 10 G70G U 8022 0039 10 0.55 bottom
SM 01 G70G 8022 0446 1 changeover
contact
0.1 0.45 side
SM 01 G70G U 8022 0447 0.1 0.45 bottom
SM 4 G70G 8022 0448 1 NC contact/
1 NO contact
4 0.55 side
SM 4 G70G U 8022 0449 4 0.55 bottom
SM 8 G70G 8022 0450 1 NC contact/
1 NO contact
8 0.60 side
SM 8 G70G U 8022 0451 8 0.60 bottom
Positive opening according to IEC/EN 60204 and IEC/EN 60947-5-1
SM 10 G70G Z 8022 0452 1 NC contact/
1 NO contact
10 1.05 side
SM 10 G70G U Z 8022 0453 10 1.05 bottom
SM 10 G70G ZO 8022 0620 2 NC contacts 10 1.05 side
SM 10 G70G U ZO 8022 0621 10 1.05 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SM 5 G90G 8022 0040 1 changeover
contact
5 0.25 side
SM 5 G90G U 8022 0041 5 0.25 bottom
SM 10 G90G 8022 0042 1 changeover
contact
10 0.45 side
SM 10 G90G U 8022 0043 10 0.45 bottom
SM 01 G90G 8022 0454 1 changeover
contact
0.1 0.35 side
SM 01 G90G U 8022 0455 0.1 0.35 bottom
SM 4 G90G 8022 0456 1 NC contact/
1 NO contact
4 0.45 side
SM 4 G90G U 8022 0457 4 0.45 bottom
SM 8 G90G 8022 0458 1 NC contact/
1 NO contact
8 0.50 side
SM 8 G90G U 8022 0459 8 0.50 bottom
Positive opening according to IEC/EN 60204 and IEC/EN 60947-5-1
SM 10 G90G Z 8022 0460 1 NC contact/
1 NO contact
10 0.80 side
SM 10 G90G U Z 8022 0461 10 0.80 bottom
SM 10 G90G Z 8022 0622 2 NC contacts 10 0.80 side
SM 10 G90G U Z 8022 0623 10 0.80 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SM 5 D85 8022 0056 1 changeover
contact
5 0.20 side
SM 5 D85 U 8022 0057 5 0.20 bottom
SM 01 D85 8022 0462 1 changeover
contact
10 0.25 side
SM 01 D85 U 8022 0463 10 0.25 bottom
NEW
Approaching angle: max 30°, approaching speed: max 3 m/s
Approaching angle: max 30°, approaching speed: max 3 m/s
24
Sub-miniature switch SM
Type table for sub-miniature switch SM, standard selection
Approaching angle: max 30°, approaching speed: max 3 m/s
Approaching angle: max 30°, approaching speed: max 3 m/s
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SM 5 D120 8022 0058 1 changeover
contact
5 0.15 side
SM 5 D120 U 8022 0059 5 0.15 bottom
SM 01 D120 8022 0464 1 changeover
contact
10 0.20 side
SM 01 D120 U 8022 0465 10 0.20 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SM 5 D200 8022 0080 1 changeover
contact
5 0.15 side
SM 5 D200 U 8022 0081 5 0.15 bottom
SM 10 D200 8022 0082 1 changeover
contact
10 0.25 side
SM 10 D200 U 8022 0083 10 0.25 bottom
SM 01 D200 8022 0466 1 changeover
contact
0.1 0.20 side
SM 01 D200 U 8022 0467 0.1 0.20 bottom
SM 4 D200 8022 0468 1 NC contact/
1 NO contact
4 0.20 side
SM 4 D200 U 8022 0469 4 0.20 bottom
SM 8 D200 8022 0470 1 NC contact/
1 NO contact
8 0.20 side
SM 8 D200 U 8022 0471 8 0.20 bottom
2525
Approaching angle: max 30°, approaching speed: max 3 m/s
Approaching angle: max 30°, approaching speed: max 3 m/s
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SM 5 K12R 8022 0016 1 changeover
contact
5 0.70 side
SM 5 K12R U 8022 0017 5 0.70 bottom
SM 10 K12R 8022 0018 1 changeover
contact
10 1.90 side
SM 10 K12RU 8022 0019 10 1.90 bottom
SM 01 K12R 8022 0472 1 changeover
contact
0.1 1.70 side
SM 01 K12R U 8022 0473 0.1 1.70 bottom
SM 4 K12R 8022 0474 1 NC contact/
1 NO contact
4 1.90 side
SM 4 K12R U 8022 0475 4 1.90 bottom
SM 8 K12R 8022 0476 1 NC contact/
1 NO contact
8 1.80 side
SM 8 K12R U 8022 0477 8 1.80 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SM 5 K27R 8022 0020 1 changeover
contact
5 0.40 side
SM 5 K27R U 8022 0021 5 0.40 bottom
SM 10 K27R 8022 0022 1 changeover
contact
10 0.85 side
SM 10 K27RU 8022 0023 10 0.85 bottom
SM 01 K27R 8022 0478 1 changeover
contact
0.1 0.70 side
SM 01 K27R U 8022 0479 0.1 0.70 bottom
SM 4 K27R 8022 0480 1 NC contact/
1 NO contact
4 0.80 side
SM 4 K27R U 8022 0481 4 0.80 bottom
SM 8 K27R 8022 0482 1 NC contact/
1 NO contact
8 0.90 side
SM 8 K27R U 8022 0483 8 0.90 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SM 5 D120 8022 0058 1 changeover
contact
5 0.15 side
SM 5 D120 U 8022 0059 5 0.15 bottom
SM 01 D120 8022 0464 1 changeover
contact
10 0.20 side
SM 01 D120 U 8022 0465 10 0.20 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SM 5 D200 8022 0080 1 changeover
contact
5 0.15 side
SM 5 D200 U 8022 0081 5 0.15 bottom
SM 10 D200 8022 0082 1 changeover
contact
10 0.25 side
SM 10 D200 U 8022 0083 10 0.25 bottom
SM 01 D200 8022 0466 1 changeover
contact
0.1 0.20 side
SM 01 D200 U 8022 0467 0.1 0.20 bottom
SM 4 D200 8022 0468 1 NC contact/
1 NO contact
4 0.20 side
SM 4 D200 U 8022 0469 4 0.20 bottom
SM 8 D200 8022 0470 1 NC contact/
1 NO contact
8 0.20 side
SM 8 D200 U 8022 0471 8 0.20 bottom
2626
Sub-miniature switch SM
Type table for sub-miniature switch SM, standard selection
Approaching angle: max 30°, approaching speed: max 3 m/s
Approaching angle: max 30°, approaching speed: max 3 m/s
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SM 5 K27K 8022 0024 1 changeover
contact
5 0.40 side
SM 5 K27K U 8022 0025 5 0.40 bottom
SM 10 K27K 8022 0026 1 changeover
contact
10 0.85 side
SM 10 K27KU 8022 0027 10 0.85 bottom
SM 01 K27K 8022 0484 1 changeover
contact
0.1 0.70 side
SM 01 K27K U 8022 0485 0.1 0.70 bottom
SM 4 K27K 8022 0486 1 NC contact/
1 NO contact
4 0.80 side
SM 4 K27K U 8022 0487 4 0.80 bottom
SM 8 K27K 8022 0488 1 NC contact/
1 NO contact
8 0.90 side
SM 8 K27K U 8022 0489 8 0.90 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SM 5 K60R 8022 0060 1 changeover
contact
5 0.20 side
SM 5 K60R U 8022 0061 5 0.20 bottom
SM 10 K60R 8022 0062 1 changeover
contact
10 0.40 side
SM 10 K60RU 8022 0063 10 0.40 bottom
SM 01 K60R 8022 0490 1 changeover
contact
0.1 0.30 side
SM 01 K60R U 8022 0491 0.1 0.30 bottom
SM 4 K60R 8022 0492 1 NC contact/
1 NO contact
4 0.40 side
SM 4 K60R U 8022 0493 4 0.40 bottom
SM 8 K60R 8022 0494 1 NC contact/
1 NO contact
8 0.40 side
SM 8 K60R U 8022 0495 8 0.40 bottom
2727
Approaching angle: max 30°, approaching speed: max 3 m/s
Approaching angle: max 30°, approaching speed: max 3 m/s
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SM 5 K27K 8022 0024 1 changeover
contact
5 0.40 side
SM 5 K27K U 8022 0025 5 0.40 bottom
SM 10 K27K 8022 0026 1 changeover
contact
10 0.85 side
SM 10 K27KU 8022 0027 10 0.85 bottom
SM 01 K27K 8022 0484 1 changeover
contact
0.1 0.70 side
SM 01 K27K U 8022 0485 0.1 0.70 bottom
SM 4 K27K 8022 0486 1 NC contact/
1 NO contact
4 0.80 side
SM 4 K27K U 8022 0487 4 0.80 bottom
SM 8 K27K 8022 0488 1 NC contact/
1 NO contact
8 0.90 side
SM 8 K27K U 8022 0489 8 0.90 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SM 5 K60R 8022 0060 1 changeover
contact
5 0.20 side
SM 5 K60R U 8022 0061 5 0.20 bottom
SM 10 K60R 8022 0062 1 changeover
contact
10 0.40 side
SM 10 K60RU 8022 0063 10 0.40 bottom
SM 01 K60R 8022 0490 1 changeover
contact
0.1 0.30 side
SM 01 K60R U 8022 0491 0.1 0.30 bottom
SM 4 K60R 8022 0492 1 NC contact/
1 NO contact
4 0.40 side
SM 4 K60R U 8022 0493 4 0.40 bottom
SM 8 K60R 8022 0494 1 NC contact/
1 NO contact
8 0.40 side
SM 8 K60R U 8022 0495 8 0.40 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SM 5 G50R 8022 0044 1 changeover
contact
5 0.40 side
SM 5 G50R U 8022 0045 5 0.40 bottom
SM 10 G50R 8022 0046 1 changeover
contact
10 0.85 side
SM 10 G50R U 8022 0047 10 0.85 bottom
SM 01 G50R 8022 0496 1 changeover
contact
0.1 0.70 side
SM 01 G50R U 8022 0497 0.1 0.70 bottom
SM 4 G50R 8022 0498 1 NC contact/
1 NO contact
4 0.70 side
SM 4 G50R U 8022 0499 4 0.70 bottom
SM 8 G50R 8022 0500 1 NC contact/
1 NO contact
8 0.75 side
SM 8 G50R U 8022 0501 8 0.75 bottom
Positive opening according to IEC/EN 60204 and IEC/EN 60947-5-1
SM 10 G50R Z 8022 0502 1 NC contact/
1 NO contact
10 1.60 side
SM 10 G50R U Z 8022 0503 10 1.60 bottom
SM 10 G50R ZO 8022 0634 2 NC contacts 10 1.60 side
SM 10 G50R U ZO 8022 0635 10 1.60 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SM 5 G70R 8022 0048 1 changeover
contact
5 0.30 side
SM 5 G70R U 8022 0049 5 0.30 bottom
SM 10 G70R 8022 0050 1 changeover
contact
10 0.55 side
SM 10 G70R U 8022 0051 10 0.55 bottom
SM 01 G70R 8022 0504 1 changeover
contact
0.1 0.45 side
SM 01 G70R U 8022 0505 0.1 0.45 bottom
SM 4 G70R 8022 0506 1 NC contact/
1 NO contact
4 0.55 side
SM 4 G70R U 8022 0507 4 0.55 bottom
SM 8 G70R 8022 0508 1 NC contact/
1 NO contact
8 0.60 side
SM 8 G70R U 8022 0509 8 0.60 bottom
Positive opening according to IEC/EN 60204 and IEC/EN 60947-5-1
SM 10 G70R Z 8022 0510 1 NC contact/
1 NO contact
10 1.05 side
SM 10 G70R U Z 8022 0511 10 1.05 bottom
SM 10 G70R ZO 8022 0624 2 NC contacts 10 1.05 side
SM 10 G70R U ZO 8022 0625 10 1.05 bottom
NEW
NEW
28
Sub-miniature switch SM
Type table for sub-miniature switch SM, standard selection
Approaching angle: max 30°, approaching speed: max 3 m/s
Approaching angle: max 30°, approaching speed: max 3 m/s
NEW
NEW
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SM 5 G90R 8022 0052 1 changeover
contact
5 0.25 side
SM 5 G90R U 8022 0053 5 0.25 bottom
SM 10 G90R 8022 0054 1 changeover
contact
10 0.45 side
SM 10 G90R U 8022 0055 10 0.45 bottom
SM 01 G90R 8022 0512 1 changeover
contact
0.1 0.35 side
SM 01 G90R U 8022 0513 0.1 0.35 bottom
SM 4 G90R 8022 0514 1 NC contact/
1 NO contact
4 0.45 side
SM 4 G90R U 8022 0515 4 0.45 bottom
SM 8 G90R 8022 0516 1 NC contact/
1 NO contact
8 0.50 side
SM 8 G90R U 8022 0517 8 0.50 bottom
Positive opening according to IEC/EN 60204 and IEC/EN 60947-5-1
SM 10 G90R Z 8022 0518 1 NC contact/
1 NO contact
10 0.90 side
SM 10 G90R U Z 8022 0519 10 0.90 bottom
SM 10 G90R ZO 8022 0626 2 NC contacts 10 0.90 side
SM 10 G90R U ZO 8022 0627 10 0.90 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SM 5 F1Kl 8022 0104 1 changeover
contact
5 0.60 side
SM 5 F1Kl U 8022 0105 5 0.60 bottom
SM 10 F1Kl 8022 0106 1 changeover
contact
10 1.10 side
SM 10 F1Kl U 8022 0107 10 1.10 bottom
SM 01 F1Kl 8022 0520 1 changeover
contact
0.1 1.00 side
SM 01 F1Kl U 8022 0521 0.1 1.00 bottom
SM 4 F1Kl 8022 0522 1 NC contact/
1 NO contact
4 2.00 side
SM 4 F1Kl U 8022 0523 4 2.00 bottom
SM 8 F1Kl 8022 0524 1 NC contact/
1 NO contact
8 2.10 side
SM 8 F1Kl U 8022 0525 8 2.10 bottom
Positive opening according to IEC/EN 60204 and IEC/EN 60947-5-1
SM 10 F1Kl Z 8022 0526 1 NC contact/
1 NO contact
10 2.60 side
SM 10 F1Kl UZ 8022 0527 10 2.60 bottom
SM 10 F1Kl ZO 8022 0628 2 NC contacts 10 2.60 side
SM 10F1Kl UZO 8022 0629 10 2.60 bottom
29
Approaching angle: max 30°, approaching speed: max 3 m/s
Operation possible from all sides
Approaching angle: max 30°, approaching speed: max 3 m/s
Operation possible from all sides
NEW
NEW
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SM 5 G90R 8022 0052 1 changeover
contact
5 0.25 side
SM 5 G90R U 8022 0053 5 0.25 bottom
SM 10 G90R 8022 0054 1 changeover
contact
10 0.45 side
SM 10 G90R U 8022 0055 10 0.45 bottom
SM 01 G90R 8022 0512 1 changeover
contact
0.1 0.35 side
SM 01 G90R U 8022 0513 0.1 0.35 bottom
SM 4 G90R 8022 0514 1 NC contact/
1 NO contact
4 0.45 side
SM 4 G90R U 8022 0515 4 0.45 bottom
SM 8 G90R 8022 0516 1 NC contact/
1 NO contact
8 0.50 side
SM 8 G90R U 8022 0517 8 0.50 bottom
Positive opening according to IEC/EN 60204 and IEC/EN 60947-5-1
SM 10 G90R Z 8022 0518 1 NC contact/
1 NO contact
10 0.90 side
SM 10 G90R U Z 8022 0519 10 0.90 bottom
SM 10 G90R ZO 8022 0626 2 NC contacts 10 0.90 side
SM 10 G90R U ZO 8022 0627 10 0.90 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SM 5 F1Kl 8022 0104 1 changeover
contact
5 0.60 side
SM 5 F1Kl U 8022 0105 5 0.60 bottom
SM 10 F1Kl 8022 0106 1 changeover
contact
10 1.10 side
SM 10 F1Kl U 8022 0107 10 1.10 bottom
SM 01 F1Kl 8022 0520 1 changeover
contact
0.1 1.00 side
SM 01 F1Kl U 8022 0521 0.1 1.00 bottom
SM 4 F1Kl 8022 0522 1 NC contact/
1 NO contact
4 2.00 side
SM 4 F1Kl U 8022 0523 4 2.00 bottom
SM 8 F1Kl 8022 0524 1 NC contact/
1 NO contact
8 2.10 side
SM 8 F1Kl U 8022 0525 8 2.10 bottom
Positive opening according to IEC/EN 60204 and IEC/EN 60947-5-1
SM 10 F1Kl Z 8022 0526 1 NC contact/
1 NO contact
10 2.60 side
SM 10 F1Kl UZ 8022 0527 10 2.60 bottom
SM 10 F1Kl ZO 8022 0628 2 NC contacts 10 2.60 side
SM 10F1Kl UZO 8022 0629 10 2.60 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SM 5 F1Kg 8022 0108 1 changeover
contact
5 0.60 side
SM 5 F1Kg U 8022 0109 5 0.60 bottom
SM 10 F1Kg 8022 0110 1 changeover
contact
10 1.10 side
SM 10 F1Kg U 8022 0111 10 1.10 bottom
SM 01 F1Kg 8022 0528 1 changeover
contact
0.1 1.00 side
SM 01 F1Kg U 8022 0529 0.1 1.00 bottom
SM 4 F1Kg 8022 0530 1 NC contact/
1 NO contact
4 2.00 side
SM 4 F1Kg U 8022 0531 4 2.00 bottom
SM 8 F1Kg 8022 0532 1 NC contact/
1 NO contact
8 2.10 side
SM 8 F1Kg U 8022 0533 8 2.10 bottom
Positive opening according to IEC/EN 60204 and IEC/EN 60947-5-1
SM 10 F1Kg Z 8022 0534 1 NC contact/
1 NO contact
10 2.60 side
SM 10 F1Kg UZ 8022 0535 10 2.60 bottom
SM 10 F1Kg ZO 8022 0630 2 NC contacts 10 2.60 side
SM 10F1Kg UZO 8022 0631 10 2.60 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SM 5 ZF1Kl 8022 0112 1 changeover
contact
5 0.60 side
SM 5 ZF1Kl U 8022 0113 5 0.60 bottom
SM 10 ZF1Kl 8022 0114 1 changeover
contact
10 1.10 side
SM 10 ZF1Kl U 8022 0115 10 1.10 bottom
SM 01 ZF1Kl 8022 0536 1 changeover
contact
0.1 1.00 side
SM 01 ZF1Kl U 8022 0537 0.1 1.00 bottom
SM 4 ZF1Kl 8022 0538 1 NC contact/
1 NO contact
4 2.00 side
SM 4 ZF1Kl U 8022 0539 4 2.00 bottom
SM 8 ZF1Kl 8022 0540 1 NC contact/
1 NO contact
8 2.10 side
SM 8 ZF1Kl U 8022 0541 8 2.10 bottom
Positive opening according to IEC/EN 60204 and IEC/EN 60947-5-1
SM 10 ZF1Kl Z 8022 0542 1 NC contact/
1 NO contact
10 2.60 side
SM 10ZF1Kl UZ 8022 0543 10 2.60 bottom
SM 10 ZF1Kl ZO 8022 0632 2 NC contacts 10 2.60 side
SM 10ZF1Kl UZO 8022 0633 10 2.60 bottom
30
Sub-miniature switch SM
Type table for sub-miniature switch SM, standard selection
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SM 5 ZF1Kg 8022 0116 1 changeover
contact
5 0.60 side
SM 5 ZF1Kg U 8022 0117 5 0.60 bottom
SM 10 ZF1Kg 8022 0118 1 changeover
contact
10 1.10 side
SM 10 ZF1Kg U 8022 0119 10 1.10 bottom
SM 01 ZF1Kg 8022 0544 1 changeover
contact
0.1 1.00 side
SM 01 ZF1Kg U 8022 0545 0.1 1.00 bottom
SM 4 ZF1Kg 8022 0546 1 NC contact/
1 NO contact
4 2.00 side
SM 4 ZF1Kg U 8022 0547 4 2.00 bottom
SM 8 ZF1Kg 8022 0548 1 NC contact/
1 NO contact
8 2.10 side
SM 8 ZF1Kg U 8022 0549 8 2.10 bottom
Positive opening according to IEC/EN 60204 and IEC/EN 60947-5-1
SM 10 ZF1Kg Z 8022 0550 1 NC contact/
1 NO contact
10 2.60 side
SM 10ZF1Kg UZ 8022 0551 10 2.60 bottom
SM 10 ZF1Kg ZO 8022 0636 2 NC contacts 10 2.60 side
SM 10ZF1Kg UZO 8022 0637 10 2.60 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SM 5 F100D 8022 0064 1 changeover
contact
5 0.10 side
SM 5 F100D U 8022 0065 5 0.10 bottom
SM 10 F100D 8022 0066 1 changeover
contact
10 0.12 side
SM 10 F100D U 8022 0067 10 0.12 bottom
SM 01 F100D 8022 0552 1 changeover
contact
0.1 0.11 side
SM 01 F100D U 8022 0553 0.1 0.11 bottom
SM 4 F100D 8022 0554 1 NC contact/
1 NO contact
4 0.16 side
SM 4 F100D U 8022 0555 4 0.16 bottom
SM 8 F100D 8022 0556 1 NC contact/
1 NO contact
8 0.17 side
SM 8 F100D U 8022 0557 8 0.17 bottom
Operation possible from all sides
Approaching angle: max 30°, approaching speed: max 3 m/s
Operation possible from all sides
NEW
31
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SM 5 ZF1Kg 8022 0116 1 changeover
contact
5 0.60 side
SM 5 ZF1Kg U 8022 0117 5 0.60 bottom
SM 10 ZF1Kg 8022 0118 1 changeover
contact
10 1.10 side
SM 10 ZF1Kg U 8022 0119 10 1.10 bottom
SM 01 ZF1Kg 8022 0544 1 changeover
contact
0.1 1.00 side
SM 01 ZF1Kg U 8022 0545 0.1 1.00 bottom
SM 4 ZF1Kg 8022 0546 1 NC contact/
1 NO contact
4 2.00 side
SM 4 ZF1Kg U 8022 0547 4 2.00 bottom
SM 8 ZF1Kg 8022 0548 1 NC contact/
1 NO contact
8 2.10 side
SM 8 ZF1Kg U 8022 0549 8 2.10 bottom
Positive opening according to IEC/EN 60204 and IEC/EN 60947-5-1
SM 10 ZF1Kg Z 8022 0550 1 NC contact/
1 NO contact
10 2.60 side
SM 10ZF1Kg UZ 8022 0551 10 2.60 bottom
SM 10 ZF1Kg ZO 8022 0636 2 NC contacts 10 2.60 side
SM 10ZF1Kg UZO 8022 0637 10 2.60 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SM 5 F100D 8022 0064 1 changeover
contact
5 0.10 side
SM 5 F100D U 8022 0065 5 0.10 bottom
SM 10 F100D 8022 0066 1 changeover
contact
10 0.12 side
SM 10 F100D U 8022 0067 10 0.12 bottom
SM 01 F100D 8022 0552 1 changeover
contact
0.1 0.11 side
SM 01 F100D U 8022 0553 0.1 0.11 bottom
SM 4 F100D 8022 0554 1 NC contact/
1 NO contact
4 0.16 side
SM 4 F100D U 8022 0555 4 0.16 bottom
SM 8 F100D 8022 0556 1 NC contact/
1 NO contact
8 0.17 side
SM 8 F100D U 8022 0557 8 0.17 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SM 5 F100F 8022 0068 1 changeover
contact
5 0.10 side
SM 5 F100F U 8022 0069 5 0.10 bottom
SM 10 F100F 8022 0070 1 changeover
contact
10 0.12 side
SM 10 F100F U 8022 0071 10 0.12 bottom
SM 01 F100F 8022 0558 1 changeover
contact
0.1 0.11 side
SM 01 F100F U 8022 0559 0.1 0.11 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SM 5 ZF100D 8022 0072 1 changeover
contact
5 0.10 side
SM 5 ZF100D U 8022 0073 5 0.10 bottom
SM 10 ZF100D 8022 0074 1 changeover
contact
10 0.12 side
SM 10 ZF100D U 8022 0075 10 0.12 bottom
SM 01 ZF100D 8022 0560 1 changeover
contact
0.1 0.11 side
SM 01 ZF100D U 8022 0561 0.1 0.11 bottom
SM 4 ZF100D 8022 0562 1 NC contact/
1 NO contact
4 0.16 side
SM 4 ZF100D U 8022 0563 4 0.16 bottom
SM 8 ZF100D 8022 0564 1 NC contact/
1 NO contact
8 0.17 side
SM 8 ZF100D U 8022 0565 8 0.17 bottom
Operation possible from all sides
Operation possible from all sides
32
Sub-miniature switch SM
Type table for sub-miniature switch SM, standard selection
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SM 5 ZF100F 8022 0076 1 changeover
contact
5 0.10 side
SM 5 ZF100F U 8022 0077 5 0.10 bottom
SM 10 ZF100F 8022 0078 1 changeover
contact
10 0.12 side
SM 10 ZF100F U 8022 0079 10 0.12 bottom
SM 01 ZF100F 8022 0566 1 changeover
contact
0.1 0.11 side
SM 01 ZF100F U 8022 0567 0.1 0.11 bottom Operation possible from all sides
33
Key
Explanation of the wiring diagrams
Contact open
Contact closed
Colour codes according to DIN IEC 757
BK black
BN brown
BU blue
GY grey
RD red
WH white
Other signs
Opening travel according to GS-ET-15
Opening contact
34
The limiting sub-miniature switches in the SDK and SDM lines
The SDK line includes plastic-encapsulated, stackable miniature dual limit switches with plastic
actuators. The sub-miniature switches in the SDM line include plastic-encapsulated, stackable
miniature dual limit switches with metal actuators. Both lines are further developments of the
successful SM line.
ASA sub-miniature switches in the SDM and SDK lines are limit switches that are especially
characterised by functionality, flexibility and versatility. They are also popular because of their
compact design and high mechanical stability. The advantage of these switch lines lies in the
smart design details: one switch is fitted with two switch inserts but has just one actuator and one supply cable. Consequently, the lines solve the problem of switching two separate
electric circuits, even when it would not be possible to arrange limit switches next to each other because of
their design.
Type key for SDK and SDM lines, standard designs
Sub-miniature switch SDK, SDM
Current capacity
5 5 Ampere
10 10 Ampere
0.1 0.1 Ampere
Fastening
Z Central fastening attachment
Actuator
S Plunger
T Telescopic plunger
K Small lever, 5 mm wide
G Large lever, 8 mm wide
D Wire
F Spring probe
Cabling
U Cable outlet, bottom
Actuator design
S Plunger
R Roller
90 Roller, 90o
offset
G Slider
K Hinge roller
D Wire
F Spring
Kl Sphere, O 8 mm
Kg Sphere, O 10 mm
Length unit for actuator
1 to 200 mm
Example: SDK 5 ZTS U
TYP
SDK Sub-miniature switch, dual limit
switch with plastic actuator
SDM Sub-miniature switch, dual limit
switch with metal actuator
35
Technical specifications for sub-miniature switch SDK and SDM lines
Regulations: ASA sub-miniature switches are manufactured in accordance with the applicable regulations IEC/EN 60204 and IEC/EN 60947-5-1
Design: Plastic-encapsulated stackable dual limit switch, sub-miniature switch design, fastening
with screws M4, DIN 85 or central fastening attachment
Housing: Thermoplastic PA 6.6 glass fibre-reinforced
Connection: PVC control cable, structure corresponds with H05VV-F, grey RAL 7001, 6 x 0.5 mm2
,
length 1m, longer or shorter cables as special designs, special cables on request
Cable inlet: side or bottom with protective rubber sleeve
Protection class: IP 65 according to IEC/EN 60529, other protection classes on request
Plunger: Thermoplastic PA 6.6 glass fibre reinforced, stainless steel, nickel-plated brass
(depending on actuator design)
Sleeve: Neoprene oil-resistant
Lever actuator: nickel-plated, cold-rolled steel, stainless steel on request
Spring actuator: Stainless steel
Roller: Thermoplastic PA 6.6 glass fibre reinforced, sintered stainless steel, nickel-plated brass
(depending on actuator design)
Actuator travel: see type table
Actuating force: see type table
Installation position: optional
Switching cycles: min. 10 million
Working temperature: -20 °C to +80 °C
Switch inserts …01… / …5... / …10…
Switch type: 1 changeover contact with
Switching system: Snap-action mechanism
Contact material: Gold/Silver/Silver
Voltage: max. 250 VAC, 40-60Hz
Current capacity: max. 0.1A / 5A / 10A
Approvals: VDE, UL, CSA
36
Sub-miniature switch SDK
Type table for sub-miniature switch SDK, standard selection
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SDK 5 S 8023 0006 2 changeover
contacts
5 1.80 side
SDK 5 S U 8023 0007 5 1.80 bottom
SDK 10 S 8023 0008 2 changeover
contacts
10 3.20 side
SDK 10 S U 8023 0009 10 3.20 bottom
SDK 01 S 8023 0010 2 changeover
contacts
0.1 2.30 side
SDK 01 S U 8023 0011 0.1 2.30 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SDK 5 T17S 8023 0018 2 changeover
contacts
5 1.80 side
SDK 5 T17S U 8023 0019 5 1.80 bottom
SDK 10 T17S 8023 0020 2 changeover
contacts
10 3.20 side
SDK 10 T17S U 8023 0021 10 3.20 bottom
SDK 01 T17S 8023 0022 2 changeover
contacts
0.1 2.30 side
SDK 01 T17S U 8023 0023 0.1 2.30 bottom
Approaching angle: max 20°, approaching speed: max 1 m/s
Approaching angle: max 20°, approaching speed: max 1 m/s
37
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SDK 5 T21S 8023 0030 2 changeover
contacts
5 1.80 side
SDK 5 T21S U 8023 0031 5 1.80 bottom
SDK 10 T21S 8023 0032 2 changeover
contacts
10 3.20 side
SDK 10 T21S U 8023 0033 10 3.20 bottom
SDK 01 T21S 8023 0034 2 changeover
contacts
0.1 2.30 side
SDK 01 T21S U 8023 0035 0.1 2.30 bottom
Approaching angle: max 20°, approaching speed: max 1 m/s
Approaching angle: max 20°, approaching speed: max 1 m/s
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SDK 5 T24S 8023 0042 2 changeover
contacts
5 2.30 side
SDK 5 T24S U 8023 0043 5 2.30 bottom
SDK 10 T24S 8023 0044 2 changeover
contacts
10 3.70 side
SDK 10 T24S U 8023 0045 10 3.70 bottom
SDK 01 T24S 8023 0046 2 changeover
contacts
0.1 2.80 side
SDK 01 T24S U 8023 0047 0.1 2.80 bottom
38
Sub-miniature switch SDK
Type table for sub-miniature switch SDK, standard selection
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SDK 5 ZS 8023 0054 2 changeover
contacts
5 1.80 side
SDK 5 ZS U 8023 0055 5 1.80 bottom
SDK 10 ZS 8023 0056 2 changeover
contacts
10 3.20 side
SDK 10 ZS U 8023 0057 10 3.20 bottom
SDK 01 ZS 8023 0058 2 changeover
contacts
0.1 2.30 side
SDK 01 ZS U 8023 0059 0.1 2.30 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SDK 5 ZTS 8023 0066 2 changeover
contacts
5 1.80 side
SDK 5 ZTS U 8023 0067 5 1.80 bottom
SDK 10 ZTS 8023 0068 2 changeover
contacts
10 3.20 side
SDK 10 ZTS U 8023 0069 10 3.20 bottom
SDK 01 ZTS 8023 0070 2 changeover
contacts
0.1 2.30 side
SDK 01 ZTS U 8023 0071 0.1 2.30 bottom
Approaching angle: max 20°, approaching speed: max 1 m/s
Approaching angle: max 20°, approaching speed: max 1 m/s
39
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SDK 5 T26R 8023 0078 2 changeover
contacts
5 1.80 side
SDK 5 T26R U 8023 0079 5 1.80 bottom
SDK 10 T26R 8023 0080 2 changeover
contacts
10 3.20 side
SDK 10 T26R U 8023 0081 10 3.20 bottom
SDK 01 T26R 8023 0082 2 changeover
contacts
0.1 2.30 side
SDK 01 T26R U 8023 0083 0.1 2.30 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SDK 5 T26R90 8023 0090 2 changeover
contacts
5 1.80 side
SDK 5 T26R90 U 8023 0091 5 1.80 bottom
SDK 10 T26R90 8023 0092 2 changeover
contacts
10 3.20 side
SDK 10 T26R90 U 8023 0093 10 3.20 bottom
SDK 01T26R90 8023 0094 2 changeover
contacts
0.1 2.30 side
SDK 01 T26R90 U 8023 0095 0.1 2.30 bottom
Approaching angle: max 30°, approaching speed: max 3 m/s
Approaching angle: max 30°, approaching speed: max 3 m/s
40
Sub-miniature switch SDK
Type table for sub-miniature switch SDK, standard selection
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SDK 5 T33R 8023 0102 2 changeover
contacts
5 1.80 side
SDK 5 T33R U 8023 0103 5 1.80 bottom
SDK 10 T33R 8023 0104 2 changeover
contacts
10 3.20 side
SDK 10 T33R U 8023 0105 10 3.20 bottom
SDK 01 T33R 8023 0106 2 changeover
contacts
0.1 2.30 side
SDK 01 T33R U 8023 0107 0.1 2.30 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SDK 5 T33R90 8023 0114 2 changeover
contacts
5 1.80 side
SDK 5 T33R90 U 8023 0115 5 1.80 bottom
SDK 10 T33R90 S 8023 0116 2 changeover
contacts
10 3.20 side
SDK 10 T33R90 U 8023 0117 10 3.20 bottom
SDK 01 T33R90 8023 0118 2 changeover
contacts
0.1 2.30 side
SDK 01 T33R90 U 8023 0119 0.1 2.30 bottom
Approaching angle: max 30°, approaching speed: max 3 m/s
Approaching angle: max 30°, approaching speed: max 3 m/s
41
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SDK 5 ZTR 8023 0126 2 changeover
contacts
5 1.80 side
SDK 5 ZTR U 8023 0127 5 1.80 bottom
SDK 10 ZTR 8023 0128 2 changeover
contacts
10 3.20 side
SDK 10 ZTR U 8023 0129 10 3.20 bottom
SDK 01 ZTR 8023 0130 2 changeover
contacts
0.1 2.30 side
SDK 01 ZTR U 8023 0131 0.1 2.30 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SDK 5 ZTR90 8023 0138 2 changeover
contacts
5 1.80 side
SDK 5 ZTR90 U 8023 0139 5 1.80 bottom
SDK 10 ZTR90 8023 0140 2 changeover
contacts
10 3.20 side
SDK 10 ZTR90 U 8023 0141 10 3.20 bottom
SDK 01 ZTR90 8023 0142 2 changeover
contacts
0.1 2.30 side
SDK 01 ZTR90 U 8023 0143 0.1 2.30 bottom
Approaching angle: max 30°, approaching speed: max 3 m/s
Approaching angle: max 30°, approaching speed: max 3 m/s
42
Sub-miniature switch SDM
Type table for sub-miniature switch SDM, standard selection
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SDM 5 S 8023 0000 2 changeover
contacts
5 1.80 side
SDM 5 S U 8023 0001 5 1.80 bottom
SDM 10 S 8023 0002 2 changeover
contacts
10 3.20 side
SDM 10 S U 8023 0003 10 3.20 bottom
SDM 01 S 8023 0004 2 changeover
contacts
0.1 2.30 side
SDM 01 S U 8023 0005 0.1 2.30 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SDM 5 T17S 8023 0012 2 changeover
contacts
5 1.80 side
SDM 5 T17S U 8023 0013 5 1.80 bottom
SDM 10 T17S 8023 0014 2 changeover
contacts
10 3.20 side
SDM 10 T17S U 8023 0015 10 3.20 bottom
SDM 01 T17S 8023 0016 2 changeover
contacts
0.1 2.30 side
SDM 01 T17S U 8023 0017 0.1 2.30 bottom
Approaching angle: max 20°, approaching speed: max 1 m/s
Approaching angle: max 20°, approaching speed: max 1 m/s
43
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SDM 5 T21S 8023 0024 2 changeover
contacts
5 1.80 side
SDM 5 T21S U 8023 0025 5 1.80 bottom
SDM 10 T21S 8023 0026 2 changeover
contacts
10 3.20 side
SDM 10 T21S U 8023 0027 10 3.20 bottom
SDM 01 T21S 8023 0028 2 changeover
contacts
0.1 2.30 side
SDM 01 T21S U 8023 0029 0.1 2.30 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SDM 5 T24S 8023 0036 2 changeover
contacts
5 2.30 side
SDM 5 T24S U 8023 0037 5 2.30 bottom
SDM 10 T24S 8023 0038 2 changeover
contacts
10 3.70 side
SDM 10 T24S U 8023 0039 10 3.70 bottom
SDM 01 T24S 8023 0040 2 changeover
contacts
0.1 2.80 side
SDM 01 T24S U 8023 0041 0.1 2.80 bottom
Approaching angle: max 20°, approaching speed: max 1 m/s
Approaching angle: max 20°, approaching speed: max 1 m/s
44
Sub-miniature switch SDM
Type table for sub-miniature switch SDM, standard selection
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SDM 5 ZS 8023 0048 2 changeover
contacts
5 1.80 side
SDM 5 ZS U 8023 0049 5 1.80 bottom
SDM 10 ZS 8023 0050 2 changeover
contacts
10 3.20 side
SDM 10 ZS U 8023 0051 10 3.20 bottom
SDM 01 ZS 8023 0052 2 changeover
contacts
0.1 2.30 side
SDM 01 ZS U 8023 0053 0.1 2.30 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SDM 5 ZTS 8023 0060 2 changeover
contacts
5 1.80 side
SDM 5 ZTS U 8023 0061 5 1.80 bottom
SDM 10 ZTS 8023 0062 2 changeover
contacts
10 3.20 side
SDM 10 ZTS U 8023 0063 10 3.20 bottom
SDM 01 ZTS 8023 0064 2 changeover
contacts
0.1 2.30 side
SDM 01 ZTS U 8023 0065 0.1 2.30 bottom
Approaching angle: max 20°, approaching speed: max 1 m/s
Approaching angle: max 20°, approaching speed: max 1 m/s
45
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SDM 5 T26R 8023 0072 2 changeover
contacts
5 1.80 side
SDM 5 T26R U 8023 0073 5 1.80 bottom
SDM 10 T26R 8023 0074 2 changeover
contacts
10 3.20 side
SDM 10 T26R U 8023 0075 10 3.20 bottom
SDM 01 T26R 8023 0076 2 changeover
contacts
0.1 2.30 side
SDM 01 T26R U 8023 0077 0.1 2.30 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SDM 5 T26R90 8023 0084 2 changeover
contacts
5 1.80 side
SDM 5 T26R90 U 8023 0085 5 1.80 bottom
SDM 10 T26R90 8023 0086 2 changeover
contacts
10 3.20 side
SDM 10 T26R90 U 8023 0087 10 3.20 bottom
SDM 01T26R90 8023 0088 2 changeover
contacts
0.1 2.30 side
SDM 01 T26R90 U 8023 0089 0.1 2.30 bottom
Approaching angle: max 30°, approaching speed: max 3 m/s
Approaching angle: max 30°, approaching speed: max 3 m/s
46
Sub-miniature switch SDM
Type table for sub-miniature switch SDM, standard selection
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SDM 5 T33R 8023 0096 2 changeover
contacts
5 1.80 side
SDM 5 T33R U 8023 0097 5 1.80 bottom
SDM 10 T33R 8023 0098 2 changeover
contacts
10 3.20 side
SDM 10 T33R U 8023 0099 10 3.20 bottom
SDM 01 T33R 8023 0100 2 changeover
contacts
0.1 2.30 side
SDM 01 T33R U 8023 0101 0.1 2.30 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SDM 5 T33R90 8023 0108 2 changeover
contacts
5 1.80 side
SDM 5 T33R90 U 8023 0109 5 1.80 bottom
SDM 10 T33R90 S 8023 0110 2 changeover
contacts
10 3.20 side
SDM 10 T33R90 U 8023 0111 10 3.20 bottom
SDM 01 T33R90 8023 0112 2 changeover
contacts
0.1 2.30 side
SDM 01 T33R90 U 8023 0113 0.1 2.30 bottom
Approaching angle: max 30°, approaching speed: max 3 m/s
Approaching angle: max 30°, approaching speed: max 3 m/s
47
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SDM 5 ZTR 8023 0120 2 changeover
contacts
5 1.80 side
SDM 5 ZTR U 8023 0121 5 1.80 bottom
SDM 10 ZTR 8023 0122 2 changeover
contacts
10 3.20 side
SDM 10 ZTR U 8023 0123 10 3.20 bottom
SDM 01 ZTR 8023 0124 2 changeover
contacts
0.1 2.30 side
SDM 01 ZTR U 8023 0125 0.1 2.30 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SDM 5 ZTR90 8023 0132 2 changeover
contacts
5 1.80 side
SDM 5 ZTR90 U 8023 0133 5 1.80 bottom
SDM 10 ZTR90 8023 0134 2 changeover
contacts
10 3.20 side
SDM 10 ZTR90 U 8023 0135 10 3.20 bottom
SDM 01 ZTR90 8023 0136 2 changeover
contacts
0.1 2.30 side
SDM 01 ZTR90 U 8023 0137 0.1 2.30 bottom
Approaching angle: max 30°, approaching speed: max 3 m/s
Approaching angle: max 30°, approaching speed: max 3 m/s
48
Sub-miniature switch SDM
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SDM 5 K12 8023 0144 2 changeover
contacts
5 1.70 side
SDM 5 K12 U 8023 0145 5 1.70 bottom
SDM 10 K12 8023 0146 2 changeover
contacts
10 3.00 side
SDM 10 K12 U 8023 0147 10 3.00 bottom
SDM 01 K12 8023 0148 2 changeover
contacts
0.1 2.00 side
SDM 01 K12 U 8023 0149 0.1 2.00 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SDM 5 K27 8023 0150 2 changeover
contacts
5 0.80 side
SDM 5 K27 U 8023 0151 5 0.80 bottom
SDM 10 K27 8023 0152 2 changeover
contacts
10 1.50 side
SDM 10 K27 U 8023 0153 10 1.50 bottom
SDM 01 K27 8023 0154 2 changeover
contacts
0.1 1.00 side
SDM 01 K27 U 8023 0155 0.1 1.00 bottom
Approaching angle: max 30°, approaching speed: max 3 m/s
Approaching angle: max 30°, approaching speed: max 3 m/s
Type table for sub-miniature switch SDM, standard selection
49
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SDM 5 K60 8023 0156 2 changeover
contacts
5 0.40 side
SDM 5 K60 U 8023 0157 5 0.40 bottom
SDM 10 K60 8023 0158 2 changeover
contacts
10 0.70 side
SDM 10 K60 U 8023 0159 10 0.70 bottom
SDM 01 K60 8023 0160 2 changeover
contacts
0.1 0.50 side
SDM 01 K60 U 8023 0161 0.1 0.50 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SDM 5 G38G 8023 0162 2 changeover
contacts
5 1.20 side
SDM 5 G38G U 8023 0163 5 1.20 bottom
SDM 10 G38G 8023 0164 2 changeover
contacts
10 2.00 side
SDM 10 G38G U 8023 0165 10 2.00 bottom
SDM 01 G38G 8023 0166 2 changeover
contacts
0.1 1.50 side
SDM 01 G38G U 8023 0167 0.1 1.50 bottom
Approaching angle: max 30°, approaching speed: max 3 m/s
Approaching angle: max 30°, approaching speed: max 3 m/s
50
Sub-miniature switch SDM
Type table for sub-miniature switch SDM, standard selection
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SDM 5 G50 8023 0168 2 changeover
contacts
5 0.80 side
SDM 5 G50 U 8023 0169 5 0.80 bottom
SDM 10 G50 8023 0170 2 changeover
contacts
10 1.50 side
SDM 10 G50 U 8023 0171 10 1.50 bottom
SDM 01 G50 8023 0172 2 changeover
contacts
0.1 1.00 side
SDM 01 G50 U 8023 0173 0.1 1.00 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SDM 5 G70 8023 0174 2 changeover
contacts
5 0.60 side
SDM 5 G70 U 8023 0175 5 0.60 bottom
SDM 10 G70 8023 0176 2 changeover
contacts
10 1.10 side
SDM 10 G70 U 8023 0177 10 1.10 bottom
SDM 01 G70 8023 0178 2 changeover
contacts
0.1 0.80 side
SDM 01 G70 U 8023 0179 0.1 0.80 bottom
Approaching angle: max 30°, approaching speed: max 3 m/s
Approaching angle: max 30°, approaching speed: max 3 m/s
51
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SDM 5 G90 8023 0180 2 changeover
contacts
5 0.40 side
SDM 5 G90 U 8023 0181 5 0.40 bottom
SDM 10 G90 8023 0182 2 changeover
contacts
10 0.70 side
SDM 10 G90 U 8023 0183 10 0.70 bottom
SDM 01 G90 8023 0184 2 changeover
contacts
0.1 0.50 side
SDM 01 G90 U 8023 0185 0.1 0.50 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SDM 5 D200 8023 0186 2 changeover
contacts
5 0.20 side
SDM 5 D200 U 8023 0187 5 0.20 bottom
SDM 01 D200 8023 0188 2 changeover
contacts
10 0.25 side
SDM 01 D200 U 8023 0189 10 0.25 bottom
Approaching angle: max 30°, approaching speed: max 3 m/s
Approaching angle: max 30°, approaching speed: max 3 m/s
52
Sub-miniature switch SDM
Type table for sub-miniature switch SDM, standard selection
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SDM 5 K12R 8023 0190 2 changeover
contacts
5 1.70 side
SDM 5 K12R U 8023 0191 5 1.70 bottom
SDM 10 K12R 8023 0192 2 changeover
contacts
10 3.00 side
SDM 10 K12RU 8023 0193 10 3.00 bottom
SDM 01 K12R 8023 0194 2 changeover
contacts
0.1 2.00 side
SDM 01 K12R U 8023 0195 0.1 2.00 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SDM 5 K27R 8023 0196 2 changeover
contacts
5 0.80 side
SDM 5 K27R U 8023 0197 5 0.80 bottom
SDM 10 K27R 8023 0198 2 changeover
contacts
10 1.50 side
SDM 10 K27RU 8023 0199 10 1.50 bottom
SDM 01 K27R 8023 0200 2 changeover
contacts
0.1 1.00 side
SDM 01 K27R U 8023 0201 0.1 1.00 bottom
Approaching angle: max 30°, approaching speed: max 3 m/s
Approaching angle: max 30°, approaching speed: max 3 m/s
53
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SDM 5 K27K 8023 0202 2 changeover
contacts
5 0.80 side
SDM 5 K27K U 8023 0203 5 0.80 bottom
SDM 10 K27K 8023 0204 2 changeover
contacts
10 1.50 side
SDM 10 K27KU 8023 0205 10 1.50 bottom
SDM 01 K27K 8023 0206 2 changeover
contacts
0.1 1.00 side
SDM 01 K27K U 8023 0207 0.1 1.00 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SDM 5 K60R 8023 0208 2 changeover
contacts
5 0.40 side
SDM 5 K60R U 8023 0209 5 0.40 bottom
SDM 10 K60R 8023 0210 2 changeover
contacts
10 0.70 side
SDM 10 K60RU 8023 0211 10 0.70 bottom
SDM 01 K60R 8023 0212 2 changeover
contacts
0.1 0.50 side
SDM 01 K60R U 8023 0213 0.1 0.50 bottom
Approaching angle: max 30°, approaching speed: max 3 m/s
Approaching angle: max 30°, approaching speed: max 3 m/s
54
Sub-miniature switch SDM
Type table for sub-miniature switch SDM, standard selection
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SDM 5 G50R 8023 0214 2 changeover
contacts
5 0.80 side
SDM 5 G50R U 8023 0215 5 0.80 bottom
SDM 10 G50R 8023 0216 2 changeover
contacts
10 1.50 side
SDM 10 G50R U 8023 0217 10 1.50 bottom
SDM 01 G50R 8023 0218 2 changeover
contacts
0.1 1.00 side
SDM 01 G50R U 8023 0219 0.1 1.00 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SDM 5 G70R 8023 0220 2 changeover
contacts
5 0.60 side
SDM 5 G70R U 8023 0221 5 0.60 bottom
SDM 10 G70R 8023 0222 2 changeover
contacts
10 1.10 side
SDM 10 G70R U 8023 0223 10 1.10 bottom
SDM 01 G70R 8023 0224 2 changeover
contacts
0.1 0.80 side
SDM 01 G70R U 8023 0225 0.1 0.80 bottom
Approaching angle: max 30°, approaching speed: max 3 m/s
Approaching angle: max 30°, approaching speed: max 3 m/s
55
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SDM 5 G90R 8023 0226 2 changeover
contacts
5 0.40 side
SDM 5 G90R U 8023 0227 5 0.40 bottom
SDM 10 G90R 8023 0228 2 changeover
contacts
10 0.70 side
SDM 10 G90R U 8023 0229 10 0.70 bottom
SDM 01 G90R 8023 0230 2 changeover
contacts
0.1 0.50 side
SDM 01 G90R U 8023 0231 0.1 0.50 bottom
Approaching angle: max 30°, approaching speed: max 3 m/s
56
Sub-miniature switch SDM
Type table for sub-miniature switch SDM, standard selection
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SDM 5 F1Kl 8023 0232 2 changeover
contacts
5 1.80 side
SDM 5 F1Kl U 8023 0233 5 1.80 bottom
SDM 10 F1Kl 8023 0234 2 changeover
contacts
10 2.80 side
SDM 10 F1Kl U 8023 0235 10 2.80 bottom
SDM 01 F1Kl 8023 0236 2 changeover
contacts
0.1 2.20 side
SDM 01 F1Kl U 8023 0237 0.1 2.20 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SDM 5 F1Kg 8023 0238 2 changeover
contacts
5 1.80 side
SDM 5 F1Kg U 8023 0239 5 1.80 bottom
SDM 10 F1Kg 8023 0240 2 changeover
contacts
10 2.80 side
SDM 10 F1Kg U 8023 0241 10 2.80 bottom
SDM 01 F1Kg 8023 0242 2 changeover
contacts
0.1 2.20 side
SDM 01 F1Kg U 8023 0243 0.1 2.20 bottom
Approaching angle: max 30°, approaching speed: max 3 m/s
Operation possible from all sides
Approaching angle: max 30°, approaching speed: max 3 m/s
Operation possible from all sides
57
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SDM 5 ZF1Kl 8023 0244 2 changeover
contacts
5 1.80 side
SDM 5 ZF1Kl U 8023 0245 5 1.80 bottom
SDM 10 ZF1Kl 8023 0246 2 changeover
contacts
10 2.80 side
SDM 10 ZF1Kl U 8023 0247 10 2.80 bottom
SDM 01 ZF1Kl 8023 0248 2 changeover
contacts
0.1 2.20 side
SDM 01 ZF1Kl U 8023 0249 0.1 2.20 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SDM 5 ZF1Kg 8023 0250 2 changeover
contacts
5 1.80 side
SDM 5 ZF1Kg U 8023 0251 5 1.80 bottom
SDM 10 ZF1Kg 8023 0252 2 changeover
contacts
10 2.80 side
SDM 10 ZF1Kg U 8023 0253 10 2.80 bottom
SDM 01 ZF1Kg 8023 0254 2 changeover
contacts
0.1 2.20 side
SDM 01 ZF1Kg U 8023 0255 0.1 2.20 bottom
Approaching angle: max 30°, approaching speed: max 3 m/s
Operation possible from all sides
Approaching angle: max 30°, approaching speed: max 3 m/s
Operation possible from all sides
58
Sub-miniature switch SDM
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SDM 5 F100D 8023 0000 2 changeover
contacts
5 0.20 side
SDM 5 F100D U 8023 0001 5 0.20 bottom
SDM 10 F100F 8023 0002 2 changeover
contacts
10 0.30 side
SDM 10 F100F U 8023 0003 10 0.30 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SDM 5 F100F 8023 0260 2 changeover
contacts
5 0.20 side
SDM 5 F100F U 8023 0261 5 0.20 bottom
SDM 10 F100F 8023 0262 2 changeover
contacts
10 0.30 side
SDM 10 F100F U 8023 0263 10 0.30 bottom
Type table for sub-miniature switch SDM, standard selection
Operation possible from all sides
Operation possible from all sides
59
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SDM 5 ZF100D 8023 0264 2 changeover
contacts
5 0.20 side
SDM 5 ZF100D U 8023 0265 5 0.20 bottom
SDM 10 ZF100D 8023 0266 2 changeover
contacts
10 0.30 side
SDM 10 ZF100D U 8023 0267 10 0.30 bottom
Type No. Contact Current
capacity
A
Wiring diagram max.
Switch B
Force N
Cable outlet
SDM 5 ZF100F 8023 0268 2 changeover
contacts
5 0.20 side
SDM 5 ZF100F U 8023 0269 5 0.20 bottom
SDM 10 ZF100F 8023 0270 2 changeover
contacts
10 0.30 side
SDM 10 ZF100F U 8023 0271 10 0.30 bottom
Operation possible from all sides
Operation possible from all sides
ASA Schalttechnik GmbH
F.-A.-Meyer-Straße 4
32457 Porta Westfalica
Germany
Phone: +49(0)571/97530-0
Fax: +49(0)571/9753080
www.asa-schalttechnik.com
info@asa-schalttechnik.de
0713/70000101
Figures and technical data are not binding. We reserve the right to make changes at any time due to technical improvements.
ระบบสมาชิก
DHL Express
FedEx Express
TNT Express
UPS Tracking
USPS Tracking
KERRY Express
EMS & Thailandpost Tracking
▲
▼
รายการสั่งซื้อของฉัน
รายการสั่งซื้อของฉัน
ข้อมูลร้านค้านี้
บริษัท ทีเอพี พาร์ท เอ็นจิเนียริ่ง จำกัด
บ.ทีเอพี พาร์ทฯ ก่อตั้งขึ้นเมื่อปี 2551 โดยกลุ่มวิศกรที่มีประสบการณ์ เราจำหน่าย-เป็นผู้นำเข้าสินค้าเองโดยตรงจากต่างประเทศ อาทิ เครื่องจักร อะไหล่วิศวกรรม อุปกรณ์ไฟฟ้าคอนโทรล เครื่องมือวัด และอุปกรณ์ต่างๆที่ใช้ในทุกกลุ่มอุตสาหกรรม ต่อมาด้วยประสบการณ์ต่างๆ เราสามารถขยายธุรกิจโดยการเป็นตัวแทนจำหน่าย รวมถึงบริการติดตั้งโครงการระบบควบคุมและสั่งการอุปกรณ์ไฟฟ้า
เบอร์โทร : 091-484-4332
อีเมล : info@tap-part.com
อีเมล : info@tap-part.com
ส่งข้อความติดต่อร้าน
เกี่ยวกับร้านค้านี้
ค้นหาสินค้าในร้านนี้
ค้นหาสินค้า
สินค้าที่ดูล่าสุด
บันทึกเป็นร้านโปรด
Join เป็นสมาชิกร้าน
แชร์หน้านี้
แชร์หน้านี้
↑
TOP เลื่อนขึ้นบนสุด
TOP เลื่อนขึ้นบนสุด
สินค้าในตะกร้า ({{total_num}} รายการ)
ขออภัย ขณะนี้ยังไม่มีสินค้าในตะกร้า
ราคาสินค้าทั้งหมด
฿ {{price_format(total_price)}}
- ฿ {{price_format(discount.price)}}
ราคาสินค้าทั้งหมด
{{total_quantity}} ชิ้น
฿ {{price_format(after_product_price)}}
ราคาไม่รวมค่าจัดส่ง
รวมภาษีมูลค่าเพิ่มแล้ว
➜ เลือกซื้อสินค้าเพิ่ม
