Actuators
A linear actuator is an actuator that creates motion in a straight line, as contrasted with circular motion of a conventional electric motor. Linear actuators are used in many industries, processes and applications where linear motion is required.
LINAK LA12
- Thanks to its small size and outstanding performance, the actuator LA12 provides a practical and cost-effective alternative to small-scale traditional hydraulic and pneumatic systems.
- The LA12 is ideal for applications requiring short linear movements. After many years on the market, the actuator LA12 demonstrated that it is a very reliable and robust actuator that can handle almost any situation and challenge.
LINAK LA14
- The actuator LA14 is a very tough actuator with a high IP degree and aluminium housing, making it ideal for use in harsh and demanding environments.
- The LA14 offers top quality in every detail and ensures reliable performance in temperatures ranging from -40° to +85 °C. With its small size the LA14 is well suited for applications that require short linear movements.
LINAK LA22
- LA22 is an in-line actuator specially designed with a small overall dimension for easy use in industrial, agricultural and rehabilitation products.
- Thanks to its small outer dimensions and linear design, LA22 is well suited for applications where installation space is limited, such as on wheelchairs.
LINAK LA27
- The LA27 actuator is a powerful actuator designed for applications such as furniture and home carebeds.
- The LA27 actuator is developed for both push and pull applications and has a very robust construction because of the ultrasonic welded plastic housing.
LINAK LA28
- The LA28 actuator is very quiet and powerful, designed for use in the CARELINE®, MEDLINE® and TECHLINE® areas of business.
- The actuator is also ideal for use in agricultural machinery and for a wide range of industrial applications.
LINAK LA29
- The LA29 actuator is a HOMELINE® actuator specially made for domestic applications.
- The actuator has a very short installation dimension as the distance between the two fixing points is small when the actuator is retracted and at the same time independent of the stroke length. This feature makes the actuator ideal as a lifting actuator for self-lifting recliners.
LINAK LA30
- LA30 is a powerful actuator yet small enough to fit to most applications.
- The actuator can be supplied with options such as built-in potentiometer for servo operation or an extra powerful motor for increased speed and strength (S-motor). In addition to Industrial Automation and Agricultural Machinery, the actuator is also ideal for positioning satellite dishes.
LINAK LA31
- The LA31 actuator is a very quiet and powerful linear actuator designed for a variety of desk applications ranging from kitchen applications to industrial table purposes.
- The LA31 actuator fits into very narrow places, as it is very compact. The LA31 is designed for use together with the DESKLINE control boxes CBD4 and CBD6S and it either can work as a single actuator or used in parallel drive.
LINAK LA32
- The LA32 is a powerful actuator that can be supplied with a ball screw spindle to give outstanding performance.
- The ideal choice for a wide range of applications including adjustment of hospital beds. The LA32 has many special options including a safety nut, splines, quick release (F) and an optional protection class up to IPX6 standard.
LINAK LA34
- LA34 is a technological state-of-the-art actuator that, due to its innovative construction can push up to 10,000 N at a speed of 5 mm/sec. and with a current consumption of approx. 7 Amp.
- The strong LA34 actuator is made in a low weight composite material and its compact design, the outstanding performance and a wide range of safety options makes LA34 the right choice for a variety of medical and industrial applications.
- The LA34 24V actuator is approved according to IEC 60601-1:2005 3rd edition, ANSI / AAMI ES60601-1:2005 3rd edition, and CAN / CSA-22.2 No 60601-1:2008.
LINAK LA35
- The LA35 is a very quiet and powerful actuator, and provides a practical and cost-effective solution with low power consumption.
- The actuator is designed for a variety of both indoor and outdoor applications.
LINAK LA36
- The actuator LA36 is one of the most solid and powerful LINAK actuators, designed to operate under extreme conditions.
- The LA36 is a maintenance-free product with a long lifetime and a high IP degree. This high-quality actuator offers a very strong alternative to hydraulic solutions.
Actuators
Actuators
A linear actuator is an actuator that creates motion in a straight line, as contrasted with circular motion of a conventional electric motor. Linear actuators are used in many industries, processes and applications where linear motion is required.
Lifting columns
Lifting columns
Lifting columns from LINAK have a compact and clean design.
They provide optimal ergonomics in applications for office and industrial markets along with the hospital and care sector. Furthermore, lifting columns can be connected in parallel to ensure adjustability for heavy objects.
Control Box
Control Box
LINAK control boxes link control units with actuators so that their movements are perfectly controlled. Various accessories can also be connected to the system through a control box.
Controls
Controls
LINAK control units are available in both basic and advanced versions with memory functions and displays for readout of height indication and other data.
Batteries
Batteries
These battery packs have been specially developed for use with the JUMBO system. The battery packs are easy to exchange through an integrated snap system and are easily mounted on the Jumbo mounting brackets.
Accessories
Accessories
LINAK provides a wide range of accessories that will add diversity to applications. The accessories are able to increase the level of comfort for the end user. Furthermore, they can help improve both user safety and working conditions.
Actuators
Actuators
A linear actuator is an actuator that creates motion in a straight line, as contrasted with circular motion of a conventional electric motor. Linear actuators are used in many industries, processes and applications where linear motion is required.
LINAK LA12
LINAK LA12
Thanks to its small size and outstanding performance, the actuator LA12 provides a practical and cost-effective alternative to small-scale traditional hydraulic and pneumatic systems.
The LA12 is ideal for applications requiring short linear movements. After many years on the market, the actuator LA12 demonstrated that it is a very reliable and robust actuator that can handle almost any situation and challenge.
Click here for the LA12 data sheet
LINAK LA14
LINAK LA14
The actuator LA14 is a very tough actuator with a high IP degree and aluminium housing, making it ideal for use in harsh and demanding environments.
The LA14 offers top quality in every detail and ensures reliable performance in temperatures ranging from -40° to +85 °C. With its small size the LA14 is well suited for applications that require short linear movements.
Click here for LA14 data sheet
LINAK LA22
LINAK LA22
LA22 is an in-line actuator specially designed with a small overall dimension for easy use in industrial, agricultural and rehabilitation products.
Thanks to its small outer dimensions and linear design, LA22 is well suited for applications where installation space is limited, such as on wheelchairs.
Click here for the LA22 data sheet
LINAK LA27
LINAK LA27
The LA27 actuator is a powerful actuator designed for applications such as furniture and home carebeds.
The LA27 actuator is developed for both push and pull applications and has a very robust construction because of the ultrasonic welded plastic housing.
Click here for the LA27 data sheet.
LINAK LA28
LINAK LA28
The LA28 actuator is very quiet and powerful, designed for use in the CARELINE®, MEDLINE® and TECHLINE® areas of business.
The actuator is also ideal for use in agricultural machinery and for a wide range of industrial applications.
Click here for the LA28 data sheet.
LINAK LA29
LINAK LA29
The LA29 actuator is a HOMELINE® actuator specially made for domestic applications.
The actuator has a very short installation dimension as the distance between the two fixing points is small when the actuator is retracted and at the same time independent of the stroke length. This feature makes the actuator ideal as a lifting actuator for self-lifting recliners.
Click here for the LA29 data sheet.
LINAK LA30
LINAK LA30
LA30 is a powerful actuator yet small enough to fit to most applications.
The actuator can be supplied with options such as built-in potentiometer for servo operation or an extra powerful motor for increased speed and strength (S-motor). In addition to Industrial Automation and Agricultural Machinery, the actuator is also ideal for positioning satellite dishes.
Click here for the LA30 data sheet.
LINAK LA31
LINAK LA31
The LA31 actuator is a very quiet and powerful linear actuator designed for a variety of desk applications ranging from kitchen applications to industrial table purposes.
The LA31 actuator fits into very narrow places, as it is very compact. The LA31 is designed for use together with the DESKLINE control boxes CBD4 and CBD6S and it either can work as a single actuator or used in parallel drive.
Click here for the LA31 data sheet.
LINAK LA32
LINAK LA32
The LA32 is a powerful actuator that can be supplied with a ball screw spindle to give outstanding performance.
The ideal choice for a wide range of applications including adjustment of hospital beds. The LA32 has many special options including a safety nut, splines, quick release (F) and an optional protection class up to IPX6 standard.
Click here for the LA32 data sheet.
LINAK LA34
LINAK LA34
LA34 is a technological state-of-the-art actuator that, due to its innovative construction can push up to 10,000 N at a speed of 5 mm/sec. and with a current consumption of approx. 7 Amp.
The strong LA34 actuator is made in a low weight composite material and its compact design, the outstanding performance and a wide range of safety options makes LA34 the right choice for a variety of medical and industrial applications.
The LA34 24V actuator is approved according to IEC 60601-1:2005 3rd edition, ANSI / AAMI ES60601-1:2005 3rd edition, and CAN / CSA-22.2 No 60601-1:2008.
Click here for the LA34 data sheet.
LINAK LA35
LINAK LA35
The LA35 is a very quiet and powerful actuator, and provides a practical and cost-effective solution with low power consumption.
The actuator is designed for a variety of both indoor and outdoor applications.
Click here for the LA35 data sheet.
LINAK LA36
LINAK LA36
The actuator LA36 is one of the most solid and powerful LINAK actuators, designed to operate under extreme conditions.
The LA36 is a maintenance-free product with a long lifetime and a high IP degree. This high-quality actuator offers a very strong alternative to hydraulic solutions.
Click here for the LA36 data sheet.
Lifting columns
LINAK DL2
LINAK DL2
The DESKLINE® DL2 column is designed for a wide range of workstation applications and it is the ideal choice for duties such as height adjustment of computer workstations, work benches, assembly desks or even kitchens.
The 2-part DL2 column can lift high loads, has a very robust design and it is compatible with the complete range of DESKLINE control boxes and controls. Depending on type of control box the system can run as a single system or 2 to 4 DL2 columns in parallel or even up to 16 columns in multi parallel.
Click here for the DL2 data sheet.
LINAK DL4
LINAK DL4
The DL4 is a DESKLIFT® lifting column.
The column is an optimum choice for a wide range of desk applications especially within the office area. The hallmarks of the DL4 are the 3-stage inline design meaning that the motor is hidden inside the profiles giving the column a very sleek and elegant design easy to integrate in various desk designs. The 3-stage construction ensures a very low built-in dimension meaning that people of all heights can use the desk.
Click here for the DL4 / DL4S data sheet.
LINAK DL5
LINAK DL5
The DESKLIFT DL5 is a compact 2-part lifting column, which is a perfect choice for a wide range of different desk applications, especially in the office area.
The DL5 has a compact motor housing, which is almost invisible in the tabletop construction. The column is very sturdy so a crossbar is not necessary. The DL5 has the same outer dimensions and mounting holes as the 3-part DL6 column, which make them compatible and they can be used in the same tabletop and table foot construction. The DL5 is available in several standard colours and lengths to fit into a wide range of desk designs.
Click here for the DL5 data sheet.
LINAK LP2
LINAK LP2
The LP2 range of vertical lifting columns is ideal where vertical positioning of substantial loads is required.
The design allows the LP2 range to be built in a complete motion control system simply by adding a suitable LINAK control box and controls. Advanced design and high quality construction, the column is ideal for operation with up to a max. of 4 units and/or with a memory function. The LP2 lifting column is the ideal choice for duties such as height adjustment of industrial workstations, technical workstations or a wide selection of other duties.
Click here for the LP2 data sheet.
Control Box
Control Box
LINAK control boxes link control units with actuators so that their movements are perfectly controlled. Various accessories can also be connected to the system through a control box.
CB6
CB6
The control box CB6 has been specially developed for use together with LA27 in the healthcare industry.
The control box is designed to be mounted on the linear actuator LA27 as with the CB9 and the LA31 system. The control box CB6 has a LED power ON indicator, detachable mains cable and strain relief for all cables.
The control box CB6 communicates with the LA27 by means of the built-in end stop signal switches in the actuator. Due to the signal switches the power to the motor will be cut off in the control box and not in the actuator. This ensures that it is only possible to run in the opposite direction once the actuator has reached the end position.
Click here for the CB6 data sheet.
CB7
CB7
Compared to other LINAK control boxes the CB7 is very small and compact in design. The CB7 is designed to slide onto an LA31 actuator for easy fitting e.g. in a recliner application where "mounting" space is limited.
The control box function is divided in two parts. The actual control box CB7, which slides onto the LA31 HOMELINE actuator and a separate external power supply transformer box TR6, which can be wall mounted or placed on the floor moulding next to the mains. The control box is only fitted with low voltage electronic components and the connection between the CB7 and transformer is via a 24 V power cable.
Click here for the CB7 data sheet.
CB8
CB8
The CB8-A is a battery powered control box operating up to 3 actuators individually. One of these channels can be used either as an external emergency stop device or for battery charging.
Click here for the CB8-A data sheet.
The CB8-T is developed for use with LINAK actuators and controls. The control box can operate up to 2 actuators individually.
Click here for the CB8-T data sheet.
CB9
CB9
The CARELINE® Basic CB9 has been developed for use together with LA31 and LA34 in the care & rehab industry.
CB9 and LA31 can be fully integrated thus saving mounting and wiring or they can be installed separately.
Click here for the CB9 Careline data sheet.
Click here for the CB9 Careline basic data sheet.
Click here for the CB9 Homeline data sheet.
CB12
CB12
The CB12 product range features three standard versions, which are ideal for many medical applications and industrial applications.
In general the CB12 can control up to 4 actuators and it has a range of built-in safety features such as battery back-up and wet alarm.
Click here for the CB12 data sheet.
CBD4
CBD4
The CBD4 control box is a sophisticated control box in the LINAK DESKLINE® product range and it is the perfect choice for all types of desks. The CBD4 ensures that the DESKLINE application has a very low and pleasant noise level and a constant speed level.
The control box is compatible with a wide range of columns, built-in actuators and the LA31 single actuator with hall print and mini fit cable, optimising logistics as you only need one box for each system.
The CBD4 ensures optimised parallel drive for 2, 3, or 4 legs in parallel or a smooth drive as a single leg control box. The control box has an extreme low power consumption of only 0.1 W in standby mode.
Click here for CBD4 data sheet.
CBD6
CBD6
The DESKLINE® control box family CBD6S (SMPS) is an optimum choice for a wide range of desk applications.
The CBD6S is perfect if you need a small and compact control box that requires a minimum of space when mounted.
The CBD6S lifts the line of intelligent DESKLINE control boxes to a new level. While keeping the advantages from earlier generations it adds so much more.
It is the most compact and lightweight control box in the DESKLINE series. It keeps the same width as DESKLINE columns with motor housings ensuring that it fi ts in a desktop frame, and it is only 38mm high.
Click here for the CBD6 / CBD6S data sheet.
CBJ1 / CBJ2
CBJ1 / CBJ2
The control boxes CBJ1 and CBJ2 are part of the battery driven JUMBO system. JUMBO is a modular system combining an actuator, a control box (CBJ1/CBJ2), a battery (BAJ1/BAJ2) and a charger (CHJ2) in a flexible solution, specially developed for patient lifts.
The complete system is medically approved and contains a series of features which meet the patients need for a safe and comfortable lift, e.g. CBJ1 and CBJ2 are equipped with a soft-start/stop function, emergency lowering function etc.
Click here for the CBJ1 / CBJ2 data sheet.
Controls
Controls
LINAK control units are available in both basic and advanced versions with memory functions and displays for readout of height indication and other data.
LINAK DP
LINAK DP
The DP (Desk Panel) is a classic control developed to adjust all kinds of desks ranging from heavy-duty workstations to office desks.
The DP is compact in design and easy to mount under various types of height adjustable desks. Optionally it can be ordered in a memory version allowing you to store favourite positions.
LINAK FS
LINAK FS
The Foot Switch is a modular system, developed for use together with LINAK control boxes.
The LINAK Foot Switch is designed for control of physiotherapeutic beds, hospital beds, dental chairs, treatment chairs, computer workstations, office desks, etc. It can also be used as a “stand alone” item for industrial applications.
Click here for the FS data sheet.
LINAK HB10
LINAK HB10
The HB10 handset series is designed for use with HOMELINE® systems for applications like leisure beds and e.g. recliners.
The HB10 handset has an ergonomic design and size and features large buttons all blending in to a user- friendly handset.
Click here for the HB10 data sheet.
LINAK HB40
LINAK HB40
The HB40 series handsets are designed for use with LINAK® control boxes.
These sturdy compact units are ergonomically designed and ideal for a vast range of applications from patient care beds and office furniture to industrial and agricultural duties.
Click here for LINAK HB40 data sheet.
LINAK HB50
LINAK HB50
The HB50 is primarily designed for the LINAK JUMBO system and LINAK control boxes with memory functions.
The HB50 gives the user access to a range of memory functions, allowing present positions to be stored. For use in a wide variety of hospital and patient care.
Click here for the HB50 data sheet.
LINAK HB60
LINAK HB60
The HB60 series is exclusively designed to be use together with the LINAK HOMELINE® system.
Click here for the HB60 data sheet.
LINAK HB70
LINAK HB70
HB70 combines ergonomic design and functionality.
LINAK offers HB70 with protection class IPX6 as standard and a range of options such as control of up to 5 actuators, memory and simultaneous drive. HB70 is designed to operate with most LINAK control boxes.
Click here for the HB70 data sheet.
LINAK HL70
LINAK HL70
HL70 is a handset with integrated locking function, where a selective locking of the different functions is available by use of a special key.
Click here for HL70 data sheet.
LINAK HD80 Jumbo
LINAK HD80 Jumbo
The HD80 JUMBO is a new hand control with an optimised ergonomic design and functions that are activated via “dome” buttons.
Click here for HD80 datasheet
LINAK RF Receiver and handset
LINAK RF Receiver and handset
The HB10RF and RFR system is a perfect choice for a wide range of adjustable furniture applications. The wireless system based on radio frequency technology (RF) is perfect for TV lift systems where cables are undesired and an infrared eye is an unwise solution.
The HB10RF handset combines ergonomic design and functionality into a user friendly handset with big intuitive buttons and without any annoying cable.
Click here for the RFR data sheet.
Batteries
Batteries
The battery packs are easy to exchange through an integrated snap system.
The battery packs are easily mounted on the JUMBO mounting brackets.
A customised front cover is possible. BAJ1 has to be charged with a JUMBO charger CHJ2 or a JUMBO control box CBJ1 or CBJ2 with integrated charger. BAJ2 can be charged as BAJ1, but can also be charged through an integrated DC-plug for use with external charger CH01.
BAJ1 is available in a special edition that can be used in the harsh conditions in the pool environment both outdoor and indoor.
Click here for BAJ battery data sheet.
Display per pageSort by
BAJ100000011
BAJ100000011
LINAK BAJ100000011 battery
£86.43 *
BAJ100000010
BAJ100000010
LINAK BAJ100000010 battery
£86.43 *
BAJ100000050
BAJ100000050
LINAK BAJ100000050 battery
£86.43 *
BAJ100000091
BAJ100000091
LINAK BAJ100000091 battery
£86.43 *
BAJ200000010
BAJ200000010
LINAK BAJ200000010 battery
£91.43 *
BAJ100000XX1
BAJ100000XX1
LINAK BAJ100000XX1 battery
£86.43 *
BAJ200000040
BAJ200000040
LINAK BAJ200000040 battery
£91.43 *
J1BA-009
J1BA-009
Battery pack
£86.43 *
BAJ10001XX1
BAJ10001XX1
LINAK BAJ10001XX1 battery
£86.43 *
Accessories
Accessories
LINAK provides a wide range of accessories that will add diversity to applications. The accessories are able to increase the level of comfort for the end user. Furthermore, they can help improve both user safety and working conditions.
CH Battery charger
CH Battery charger
The CH battery charger gives the possibility to interchange the plug type with a simple “slide on” operation. This gives great versatility and a logistical advantage reducing stocks and costs.
Click here for the CH data sheet
CHJ2
CHJ2
The charger CHJ2 has been specially designed for use as a wall-charger for the JUMBO system.
The CHJ2 charger is a Switch Mode Power Supply (SMPS) version which makes charging of the batteries more efficient. The charging time for a BAJ1 or a BAJL (Standard) battery pack is approx. 4 hours. Mains voltage from 100 V AC - 240 V AC (50/60 Hz) is possible on same charger. The charger indicates whether the charger is connected to the mains (green LED) or whether the battery is being charged (yellow LED). Medically approved.
Click here for the CHJ2 data sheet
LS / LSD
LS / LSD
There are two types of LINAK® limit switches, for actuators type LA22, LA30, LA30S, LS and LSD.
The LSD type controls the stroke length of the actuator between two fixed end positions by cutting off the current to the motor. The LS type gives signal in two fixed end positions, but requires a control unit to stop the actuator when the micro switches are activated.
Click here for the LS / LSD data sheet.
MBJ
MBJ
Depending on what your JUMBO system consists of you need to use one of the following three mounting brackets MBJ1, MBJ2, or MBJ3.
Click here for the MBJ data sheet.
TR6 / TR7
TR6 / TR7
The TR6 is a separate external power supply box, which can be wall-mounted or placed on the floor. It replaces the TR7.
The TR6 operates via a 24V power cable.
Click here for the TR6 data sheet.
TR-EM Motor controller
TR-EM Motor controller
TR-EM-208 is designed specially for spindle motor use.
Adjustable soft start, soft stop and current limit are main features of the card. Additionally impulse or continuous type control can be selected as the control mode. Control input can be set to positive or negative (gnd) logic.
Click here for the TR-EM data sheet.
