Eleco SUS-95
LED
Red Green 230AC
SWITCH POSITION INDICATOR
Operating voltage : 12-230V AC, DC
Nominal current : max. 20mA
IP protection : IP65
Panel thickness : max. 12 mm
Connecting conductor diameter : 2,5 mm²
Holes spacing : minimal 40 mm
LED colour : R, G, B, Y, W, O
Dimensions : ø39 mm, length 75 mm, length behind the panel 57 mm
Mounting hole : 22 mm
Warning : Upper cover of the indicator may be supplied in various colour designs, standard colour is black.
